3 Illustrated parts catalog
To identify the monitor major components, use this illustration and table.
 524sf/524sw/524sa
item
Description
Qty
1 Encore 3.5 524sf 524sh
1
Encore 3.5 524sw 524sa
1
2 WH A1007H00-6P-2L/A1257H00-6P-L #28 75mm(Delete pin4) W/B HF 1
WH A1007H00-6P-2L/A1257H00-6P-L #28 95mm+ACETATE(Delete pin4) W/B HF 1
3 WH FFC 30P(1.0mm)180mm(1FOLD+PRO)60V G/F W/CONN(A15+BC)+AL HFPOWER LENS (PC/TRANSPARENT)(OCEAN 20) 1
4 WH FFC 8P(0.5mm)270mm(3FOLD)60V G/F (A8+A6) HF21.5 LCM for HP Ocean’2021.5 HP Ocean LM215WF9-HSAN1 1
5
Audio BD ASS'Y HP Encore 3.5 TTS Board (MT9052) 2LMID FRAME FOR LHD (ABS+85% recycle ABS /JACK BACK (6009-0337))(OCEAN 20
P22 G5)
1
6
REAR SUPPORT-L(PCR-85% ABS+5% PET/JACK BLACK (6009-0337))WH FFC 30P(1.0mm) 380mm(2FOLD) 60V G/F W/CONN
(A15+BC)+AL(AA) HF
1
7 REAR SUPPORT-R(PCR-85% ABS+5% PET/JACK BLACK (6009-0337))WH FFC 8P(0.5mm) 560mm(2FOLD+1PRO) 60V G/F (A8+A5) HF 1
8 MAC. SCREW-MI M3.0*4.0L,NI WH A1007H00-6P-L/KY1251HS05-06 #28 450mm W/B HF 16
9 MYLAR BLACK(150*40*0.325t) (ENCORE 3-M24F LGD PANEL)MAIN BD ASS'Y HP P22 G5 (M215HCA) 2L 1
MYLAR BLACK(16.5*15*0.325t) (ENCORE 3-SHIELDING MIDDLE SCREW) 1
10 MAIN BD ASS'Y HP Encore 3.5 524sf (LM238WF8-SJA1) 2LPower BD ASS'Y (HP Ocean 20 25W POWER BD) 1
MAIN BD ASS'Y HP Encore 3.5 524sw (LM238WF8-SJA1) 2L 1
