HP 7500 Switch Series
Specifications
HP 7510 Switch Chassis (JD238B) HP 7506-V Switch Chassis (JD241B) HP 7506 Switch Chassis (JD239B)
Included accessories
1 HP 7510 Spare Fan Assembly (JD216A) 1 HP 7506-V Spare Fan Assembly (JD215A) 1 HP 7506 Spare Fan Assembly (JD214A)
Ports
2 switch fabric slots
10 I/O module slots
Supports a maximum of 84 10-GbE ports or 480
autosensing 10/100/1000 ports or 480 SFP ports,
or a combination
2 switch fabric slots
6 I/O module slots
Supports a maximum of 52 10-GbE ports or 288
autosensing 10/100/1000 ports or 288 SFP ports,
or a combination
2 switch fabric slots
6 I/O module slots
Supports a maximum of 52 10-GbE ports or 288
autosensing 10/100/1000 ports or 288 SFP ports,
or a combination
Power supplies
2 power supply slots
1 minimum power supply required (ordered
separately)
2 power supply slots
1 minimum power supply required (ordered
separately)
2 power supply slots
1 minimum power supply required (ordered
separately)
Fan tray
includes: 1 x JD216A
1 fan tray slot
includes: 1 x JD215A
1 fan tray slot
includes: 1 x JD214A
1 fan tray slot
Physical characteristics
17.17(w) x 16.54(d) x 27.87(h) in (43.6 x 42.0 x
70.8 cm) (16U height)
17.17(w) x 16.54(d) x 36.61(h) in (43.6 x 42.0 x
93.0 cm) (21U height)
17.17(w) x 16.54(d) x 22.64(h) in (43.6 x 42.0 x
57.5 cm) (13U height)
Weight
211 lb (95.71 kg), Fully loaded chassis, two
fabrics, two power supplies, and a full complement
of typical I/O modules
222 lb (100.7 kg), Fully loaded chassis, two
fabrics, two power supplies, and a full complement
of typical I/O modules
207 lb (93.9 kg), Fully loaded chassis, two fabrics,
two power supplies, and a full complement of
typical I/O modules
Memory and processor
Fabric
MIPS64 @ 600 MHz, 64 MB flash, 512 MB RAM MIPS64 @ 600 MHz, 64 MB flash, 512 MB RAM MIPS64 @ 600 MHz, 64 MB flash, 512 MB RAM
I/O module
MIPS64 @ 400 MHz, 512 MB RAM MIPS64 @ 400 MHz, 512 MB RAM MIPS64 @ 400 MHz, 512 MB RAM
Mounting
Mounts in an EIA-standard 19 in. rack or other
equipment cabinet (hardware included); horizontal
surface mounting only
Mounts in an EIA-standard 19 in. rack or other
equipment cabinet (hardware included); horizontal
surface mounting only
Mounts in an EIA-standard 19 in. rack or other
equipment cabinet (hardware included); horizontal
surface mounting only
Performance
Throughput
714 million pps 488 million pps 488 million pps
Routing/Switching capacity
1152 Gbps 768 Gbps 768 Gbps
Routing table size
256000 entries 256000 entries 256000 entries
MAC address table size
512000 entries 512000 entries 512000 entries
Reliability
Availability
99.999% 99.999% 99.999%
Environment
Operating temperature
32°F to 113°F (0°C to 45°C) 32°F to 113°F (0°C to 45°C) 32°F to 113°F (0°C to 45°C)
Operating relative humidity
10% to 95%, noncondensing 10% to 95%, noncondensing 10% to 95%, noncondensing
Nonoperating/Storage temperature
-40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage relative humidity
5% to 95%, noncondensing 5% to 95%, noncondensing 5% to 95%, noncondensing
Acoustic
Low-speed fan: 53.5 dB, High-speed fan: 56.7 dB Low-speed fan: 52.1 dB, High-speed fan: 56.2 dB Low-speed fan: 53.6 dB, High-speed fan: 57.7 dB
Electrical characteristics
Achieved Miercom Certified Green Award
Description
The H3C S7506E (HP 7606) is Certified Green in
the 2009 Miercom Green Switches Industry
Assessment.
Voltage
100-120/200-240 VAC 100-120/200-240 VAC 100-120/200-240 VAC
DC voltage
-48 to -60 VDC -48 to -60 VDC -48 to -60 VDC
Current
16/50 A 16/50 A 16/50 A
Power output
1400 W 1400 W 1400 W
Frequency
50/60 Hz 50/60 Hz 50/60 Hz
Notes
Based on a common power supply of 1400 W
(AC/DC)
Based on a common power supply of 1400 W
(AC/DC)
Based on a common power supply of 1400 W
(AC/DC)
Safety
UL 60950-1; IEC 60950-1; CAN/CSA-C22.2 No.
60950-1; EN 60950-1/A11
UL 60950-1; IEC 60950-1; CAN/CSA-C22.2 No.
60950-1; EN 60950-1/A11
UL 60950-1; IEC 60950-1; CAN/CSA-C22.2 No.
60950-1; EN 60950-1/A11
Emissions
VCCI Class A; EN 55022 Class A; ICES-003 Class
A; ANSI C63.4 2003; AS/NZS CISPR22 Class A;
EN 61000-3-2:2006; EN 61000-3-3:1995
+A1:2001+A2:2005; EMC Directive
2004/108/EC; FCC (CFR 47, Part 15) Class A
VCCI Class A; EN 55022 Class A; ICES-003 Class
A; ANSI C63.4 2003; AS/NZS CISPR22 Class A;
EN 61000-3-2:2006; EN 61000-3-3:1995
+A1:2001+A2:2005; EMC Directive
2004/108/EC; FCC (CFR 47, Part 15) Class A
VCCI Class A; EN 55022 Class A; ICES-003 Class
A; ANSI C63.4 2003; AS/NZS CISPR22 Class A;
EN 61000-3-2:2006; EN 61000-3-3:1995
+A1:2001+A2:2005; EMC Directive
2004/108/EC; FCC (CFR 47, Part 15) Class A
Immunity
Generic
ETSI EN 300 386 V1.3.3 ETSI EN 300 386 V1.3.3 ETSI EN 300 386 V1.3.3
EN
EN 61000-4-2:1995+A1:1998+A2:2001 EN 61000-4-2:1995+A1:1998+A2:2001 EN 61000-4-2:1995+A1:1998+A2:2001
ESD
EN 61000-4-2 EN 61000-4-2 EN 61000-4-2

HP 7510 Specifications

General

Brand	HP
Model	7510
Category	Switch
Language	English
