HP Compaq 8200 User Manual

Maximum Data Transfer Rates
DVD-RW up to 10X
DVD+R DL up to 8X
DVD-R DL up to 8X
DVD-ROM up to 16X
DVD-ROM DL up to 8X
DVD+R up to 12X
DVD-R up to 12X
Blu-ray BD-ROM up to 6X
BD-ROM DL up to 4.8X
BD-R up to 6X
BD-R DL up to 4.8X
BD-R up to 6X
BD-RE SL/DL up to 4.8X
Power Source SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p
DC Current 5 VDC -1000 mA typical, 1600 mA maximum
12 VDC -600 mA typical, 1400 mA maximum
Environmental
(all conditions
non-condensing)
Temperature (operating) 41° to 122° F (5° to 50° C)
Relative Humidity (operating) 10% to 90%
Maximum Wet Bulb
Temperature (operating)
86° F (30° C)
HP SuperMulti DVD Writer Drive
AMO Part Number AR630AT
Height 5.25-inch, half-height, tray-load
Orientation Either horizontal or vertical
Interface type Serial ATA
Dimensions (W x H x D) 5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)
Weight (max) 2.6 lb (1.2 kg)
CD Media Read Access
Random < 120 ms typical
Full Stroke < 200 ms typical
DVD Media Read Access
Random < 130 ms typical
Full Stroke < 240 ms typical
QuickSpecs
HP Compaq 8200 Elite Series
Technical Specifications - Removable Storage
DA - 13879 North America — Version 36 — August 15, 2013 Page 60
