Basic Windows PS/2
Keyboard
(SK-1688A)
Physical
characteristics
Keys 104, 105, 106, 107, 109 layout (depending
upon country)
Dimensions (L x W x H) 18.1 x 6.7 x 1.3 in (46 x 17 x 3.4 cm)
Weight 1.9 lb (0.86 kg) minimum
Electrical Operating voltage + 5VDC ± 5%
Power consumption 50-mA maximum (with three LEDs ON)
System interface PS2 6-pin DIN connector
ESD CE level 4, 15-kV air discharge
EMI – RFI Conforms to FCC rules for a Class B
computing device
Microsoft ® PC 99 –
2001
Functionally compliant
Mechanical Languages 38 available
Keycaps Low-profile design
Switch actuation 55-g nominal peak force with tactile feedback
Switch life 20 million keystrokes (using Hasco modified
tester)
Switch type Contamination-resistant switch membrane
Key-leveling
mechanisms
For all double-wide and greater-length keys
Cable length 4.5 ft (1.35 m)
Microsoft PC 99 – 2001 Mechanically compliant
Acoustics 43-dBA maximum sound pressure level
Environmental Operating temperature 50° to 122° F (10° to 50° C)
Non-operating
temperature
-22° to 140° F (-30° to 60° C)
Non-operating humidity 20% to 80% (non-condensing at ambient)
Operating shock 40 g, six surfaces
Non-operating shock 80 g, six surfaces
Operating vibration 2-g peak acceleration
Non-operating
vibration
4-g peak acceleration
Drop (out of box) 14.9 in (38 cm) on carpet, six-drop sequence
Drop (in box) 29.9 in (76 cm) on concrete, 16-drop
sequence
Approvals UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC
Ergonomic compliance ANSI HFS 100, ISO 9241-4, and TUVGS
QuickSpecs
HP Compaq Business Desktop dx2000 microtower
Technical Specifications - Input/Output Devices
DA - 11851 North America — Version 37 — March 21, 2007 Page 23
