3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 39), and then remove the following components:
●
WLAN module (see
WLAN module on page 48)
●
Hard drive (see
Hard drive on page 53)
●
Keyboard (see
Keyboard on page 58)
●
Top cover (see
Top cover on page 61)
●
Speakers (see
Speakers on page 69)
●
USB board (see
USB board on page 71)
●
Power connector cable (see
Power connector cable on page 73)
●
Display assembly (see
Display assembly on page 75)
●
System board (see
System board on page 84)
●
Fan/heat sink assembly (see
Fan/heat sink assembly on page 90)
To remove the processor:
1. Use a flat-bladed screw driver (1) to turn the processor locking screw one-half turn
counterclockwise (2) until you hear a click.
ENWW Component replacement procedures 97
