HP Compaq dc5800 Specifications

DVI ADD2 Graphics
DVI ADD2 GraphicsDVI ADD2 Graphics
DVI ADD2 Graphics
1
11
1
Models
ModelsModels
Models HP ADD2 SDVO DVI-D Out Adapter
Form Factor
Form FactorForm Factor
Form Factor Low-profile card
DVI-D Connector
DVI-D ConnectorDVI-D Connector
DVI-D Connector Digital connection only
Dual Head Support
Dual Head SupportDual Head Support
Dual Head Support Yes, when used with the integrated VGA connector
Display Devices
Display DevicesDisplay Devices
Display Devices
Supported
SupportedSupported
Supported
HP L1740
HP L1940T
HP L2045W
HP LP1965
NOTE:
NOTE: NOTE:
NOTE: These graphics adapters offer optimal performance with any display that meets applicable VESA
standards.
Colour Depth
Colour DepthColour Depth
Colour Depth All modes support 8-bpp, 16-bpp, and 24-bpp colour depths
Host Interface Connector
Host Interface ConnectorHost Interface Connector
Host Interface Connector Mechanically compliant with PCI-E standard
Complies with the Intel ADD2 and Intel Serial Digital Video Output (SDVO)
specifications
Dot Clock
Dot ClockDot Clock
Dot Clock 165 MHz maximum
Display Modes
Display ModesDisplay Modes
Display Modes Supports display modes that require up to 165-MHz bandwidth on the link,
as shown in the following table.
Resolution
ResolutionResolution
Resolution 60-Hz LCD
60-Hz LCD60-Hz LCD
60-Hz LCD 60-Hz
60-Hz60-Hz
60-Hz 75-Hz
75-Hz75-Hz
75-Hz 85-Hz
85-Hz85-Hz
85-Hz
Blanking 5% reduced GTF GTF GTF
640 x 480 VGA Yes Yes Yes Yes
800 x 600 SVGA Yes Yes Yes Yes
1024 x 768 XGA Yes Yes Yes Yes
1280 x
1024
SXGA Yes Yes No No
1600 x
1200
UXGA Yes Yes No No
ATI Radeon HD 3470
ATI Radeon HD 3470ATI Radeon HD 3470
ATI Radeon HD 3470
(256MB SH) PCIe x16
(256MB SH) PCIe x16(256MB SH) PCIe x16
(256MB SH) PCIe x16
Graphics Card
Graphics CardGraphics Card
Graphics Card
Bus type
Bus typeBus type
Bus type PCI Express (x16 lanes)
Maximum vertical refresh
Maximum vertical refreshMaximum vertical refresh
Maximum vertical refresh
rate
raterate
rate
85 Hz
Display support
Display supportDisplay support
Display support Integrated 400 MHz RAMDAC
Display max resolution
Display max resolutionDisplay max resolution
Display max resolution 2560x1600 digital, 2048 x 1536 analog
Board display options
Board display optionsBoard display options
Board display options Supports two displays via the DisplayPort and DVI connectors
Board configuration
Board configurationBoard configuration
Board configuration Specification
SpecificationSpecification
Specification Description
DescriptionDescription
Description
Graphics Chip RV620
Core clock 750 MHz
Memory clock 500 MHz
Frame buffer
Frame bufferFrame buffer
Frame buffer 256 MB DDR2, 64 bit wide
Languages supported
Languages supportedLanguages supported
Languages supported 24 languages: English, Arabic, Chinese Simplified, Chinese Traditional,
Czechoslovakian, Danish, Dutch, Finnish, French, German, Greek, Hebrew,
Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese,
Russian, Spanish, Swedish, Thai, Turkish
Operating systems
Operating systemsOperating systems
Operating systems
support
supportsupport
support
Windows Vista Business 64 * , Windows Vista Business 32 * , Windows Vista
Home Basic 32 * , Windows XP Professional or Windows XP Home 32 * .
QuickSpecs
HP Compaq dc5800 Business PC
HP Compaq dc5800 Business PCHP Compaq dc5800 Business PC
HP Compaq dc5800 Business PC
Technical Specifications - Graphics
DA - 12863 Canada — Version 24 — July 31, 2009 Page 31

HP Compaq dc5800 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Total storage capacity	250 GB
Audio system	High Definition Audio
Product type	PC
Drive bays	2 external 5.25 inch, 1 external 3.5 inch 2 internal 3.5 inch
Driver LAN	Microsoft Windows XP, Microsoft Windows Vista, FreeDos, Linux
LightScribe	Yes
Upgrade type	Windows Vista capable
Keyboard type	HP PS/2 Standard Keyboard
Audio included	Integrated High Definition audio with ADI1884 codec, microphone and headphone front ports, line-out and line-in rear ports, multistreaming capable, internal PC speaker
Diskette drive	Optional
Expansion slots	1 full-height PCI, 1 full-height PCI Express x16, 2 full-height PCI Express x1
Pointing device	HP PS/2 2-Button Optical Scroll Mouse
Power management	Operating Voltage Range: 90 – 264 VAC; Rated Voltage Range: 100 – 240 VAC; Rated Line Frequency: 50/60 Hz; Operating Line Frequency Range: 47 – 63 Hz; Rated Input Current 80 Plus: 2.5 A; Current Leakage (NFPA 99): \u003C 275 µA; System Heat Dissipation 80 Plus: Typical 315 btu/hr (79 kg-cal/hr), Maximum 1575 btu/hr (397 kg-cal/hr; Power Supply Fan: Variable speed fan, Power Consumption in ES Mode – Suspend to RAM (S3) (Instantly Available PC): \u003C4 W
Security features	Kensington Lock
Power requirements	Input voltage 90 – 264 / 100 – 240 VAC, 50/60 Hz, 47 – 63 Hz, active PFC optional (External 80% High Efficiency) Operating Voltage Range: 90 – 264 VAC; Rated Voltage Range: 100 – 240 VAC; Rated Line Frequency: 50/60 Hz; Operating Line Frequency Range: 47 – 63 Hz; Rated Input Current 80 Plus: 2.5 A; Current Leakage (NFPA 99): \u003C 275 µA; System Heat Dissipation 80 Plus: Typical 315 btu/hr (79 kg-cal/hr), Maximum 1575 btu/hr (397 kg-cal/hr; Power Supply Fan: Variable speed fan, Power Consumption in ES Mode – Suspend to RAM (S3) (Instantly Available PC): \u003C4 W
External drive bays	2x 5.25\
Networking features	Gigabit Ethernet
Video card features	3D/2D Controller: support is fully compliant with Microsoft standard API such as Microsoft DirectX9, DirectXVA, VMR9, GDI/GDI+; OpenGL 1.4.; Integrated VGA Controller; integrated 350 MHz RAMDAC; 400 MHz Controller Clock Speed; Overlay Planes: Single overlay support with 5x3 filtering; Maximum Color Depth: 32 bits/pixel; Multi-display Support: 2 displays can be supported via the motherboard's VGA connectors and SDVO/ADD2 option Intel Graphics Media Accelerator 3100 \u003C85 Hz @ 1920x1440, 75 Hz @ 2048x1536
Acoustic power emissions	IDLE (Fixed disk drive spinning): LWAd = 3.8 Bels; FIXED DISK (Random write): LWAd = 3.9 Bels
Non-operating relative humidity (non-condensing)	5 - 90 %
Bundled software	On some models only (not included with FreeDOS): HP ProtectTools Security Solutions, HP Backup and Recovery Manager, HP Insight Diagnostics (available via HP Backup and Recovery Manager), HP Software Agent, HP Total Care Advisor, HP Client Configuration Manager, HP Client Manager for Altiris, HP SoftPaq Download Manager, HP Client Catalog for Microsoft SMS, HP Systems Software Manager, Computer Setup Utility, Altiris Out-of-Band Management Solution, McAfee AntiVirus trial version, Roxio DigitalMedia Plus 7.2/Easy Media Creator 9 Optional preloaded software, only for certain configurations: PDF Complete, Computrace for Desktops, Verdiem Surveyor agent, InterVideo WinDVD 5.0, Microsoft Office 2007 Basic, Microsoft Office 2007 Professional, Microsoft Office 2007 Small Business, Microsoft Internet Explorer with AOL Toolbar
Applications supported	Windows Vista Premium ready
Operating system installed	Windows Vista Business
Compatible operating systems	FreeDOS
Optional operating system supplied	Windows XP Professional
I/O ports	Rear: 6 USB 2.0, 1 serial port, 1 optional serial port, 1 optional parallel port, 2 PS/2, 1 RJ-45, 1 VGA, audio in/out; Front: 2 USB 2.0, audio ports
Serial ports quantity	1
USB 2.0 ports quantity	8
Parallel ports quantity	0
Chassis type	Micro Tower
Country of origin	China
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 9144 m
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Discrete graphics card model	Intel® GMA 3100
Maximum graphics card memory	0.256 GB
On-board graphics card model	Not available
Power consumption (typical)	300 W
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	428 mm
Width	176 mm
Height	377 mm
Weight	8900 g
Package weight	4450 g
