HP Compaq dc5800 Specifications

Eco-Label Certifications
Eco-Label CertificationsEco-Label Certifications
Eco-Label Certifications
and declarations
and declarationsand declarations
and declarations
This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:
US ENERGY STAR®
US Federal Energy Management Program (FEMP)
Taiwan Green Mark
China Energy Conservation Program
IT ECO declaration
EPEAT™ Rated – GOLD
Korea Eco-label
Japan PC Green label*
* This product conforms to the examination standards (2003 version) under JEITA's 'PC Green Label
System.'
Small Form Factor
Small Form FactorSmall Form Factor
Small Form Factor
System Configuration
System ConfigurationSystem Configuration
System Configuration The configuration used for the Energy Consumption and Declared Noise Emissions data for the Small
Form Factor Desktop model is based on a typically configured product.
Energy Consumption
Energy ConsumptionEnergy Consumption
Energy Consumption AC Input Voltage at 115 VAC
AC Input Voltage at 115 VACAC Input Voltage at 115 VAC
AC Input Voltage at 115 VAC
+/- 5 VAC, 60 Hz +/- 3 Hz
+/- 5 VAC, 60 Hz +/- 3 Hz+/- 5 VAC, 60 Hz +/- 3 Hz
+/- 5 VAC, 60 Hz +/- 3 Hz
AC Input Voltage at 230 VAC
AC Input Voltage at 230 VACAC Input Voltage at 230 VAC
AC Input Voltage at 230 VAC
+/- 5 VAC, 50 Hz +/- 3 Hz
+/- 5 VAC, 50 Hz +/- 3 Hz+/- 5 VAC, 50 Hz +/- 3 Hz
+/- 5 VAC, 50 Hz +/- 3 Hz
AC Input Voltage at 100 VAC
AC Input Voltage at 100 VACAC Input Voltage at 100 VAC
AC Input Voltage at 100 VAC
+/- 5 VAC, 50 Hz +/- 3 Hz
+/- 5 VAC, 50 Hz +/- 3 Hz+/- 5 VAC, 50 Hz +/- 3 Hz
+/- 5 VAC, 50 Hz +/- 3 Hz
Normal Operation On-
Idle (ENERGY STAR Idle
(S0))
56.48 W 55.47 W 57.01 W
ENERGY STAR “Sleep”
(S3) (Wake On LAN
(WOL) Enabled)
3.28 W 3.56 W 3.27 W
ENERGY STAR “Sleep”
(S3) (Wake On LAN
(WOL) Disabled)
3.28 W 3.56 W 3.27 W
ENERGY STAR “Standby”
(Off) (S5) (Wake On LAN
(WOL) Enabled)
1.6 W 1.87 W 1.58 W
ENERGY STAR “Standby”
(Off) (S5) (Wake On LAN
(WOL) Disabled)
0.9 W 1.16 W 0.88 W
Heat Dissipation*
Heat Dissipation*Heat Dissipation*
Heat Dissipation* AC Input Voltage at 115 VAC
AC Input Voltage at 115 VACAC Input Voltage at 115 VAC
AC Input Voltage at 115 VAC
+/- 5 VAC, 60 Hz +/- 3 Hz
+/- 5 VAC, 60 Hz +/- 3 Hz+/- 5 VAC, 60 Hz +/- 3 Hz
+/- 5 VAC, 60 Hz +/- 3 Hz
AC Input Voltage at 230 VAC
AC Input Voltage at 230 VACAC Input Voltage at 230 VAC
AC Input Voltage at 230 VAC
+/- 5 VAC, 50 Hz +/- 3 Hz
+/- 5 VAC, 50 Hz +/- 3 Hz+/- 5 VAC, 50 Hz +/- 3 Hz
+/- 5 VAC, 50 Hz +/- 3 Hz
AC Input Voltage at 100 VAC
AC Input Voltage at 100 VACAC Input Voltage at 100 VAC
AC Input Voltage at 100 VAC
+/- 5 VAC, 50 Hz +/- 3 Hz
+/- 5 VAC, 50 Hz +/- 3 Hz+/- 5 VAC, 50 Hz +/- 3 Hz
+/- 5 VAC, 50 Hz +/- 3 Hz
Normal Operation On-
Idle (ENERGY STAR Idle
(S0))
192.709 BTU/hr 189.263 BTU/hr 194.518 BTU/hr
ENERGY STAR “Sleep”
(S3) (Wake On LAN
(WOL) Enabled)
11.191 BTU/hr 12.146 BTU/hr 11.147 BTU/hr
ENERGY STAR “Sleep”
(S3) (Wake On LAN
(WOL) Disabled)
11.191 BTU/hr 12.146 BTU/hr 11.147 BTU/hr
QuickSpecs
HP Compaq dc5800 Business PC
HP Compaq dc5800 Business PCHP Compaq dc5800 Business PC
HP Compaq dc5800 Business PC
Technical Specifications - Environmental Data
DA - 12863 Canada — Version 24 — July 31, 2009 Page 47

HP Compaq dc5800 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Total storage capacity	250 GB
Audio system	High Definition Audio
Product type	PC
Drive bays	2 external 5.25 inch, 1 external 3.5 inch 2 internal 3.5 inch
Driver LAN	Microsoft Windows XP, Microsoft Windows Vista, FreeDos, Linux
LightScribe	Yes
Upgrade type	Windows Vista capable
Keyboard type	HP PS/2 Standard Keyboard
Audio included	Integrated High Definition audio with ADI1884 codec, microphone and headphone front ports, line-out and line-in rear ports, multistreaming capable, internal PC speaker
Diskette drive	Optional
Expansion slots	1 full-height PCI, 1 full-height PCI Express x16, 2 full-height PCI Express x1
Pointing device	HP PS/2 2-Button Optical Scroll Mouse
Power management	Operating Voltage Range: 90 – 264 VAC; Rated Voltage Range: 100 – 240 VAC; Rated Line Frequency: 50/60 Hz; Operating Line Frequency Range: 47 – 63 Hz; Rated Input Current 80 Plus: 2.5 A; Current Leakage (NFPA 99): \u003C 275 µA; System Heat Dissipation 80 Plus: Typical 315 btu/hr (79 kg-cal/hr), Maximum 1575 btu/hr (397 kg-cal/hr; Power Supply Fan: Variable speed fan, Power Consumption in ES Mode – Suspend to RAM (S3) (Instantly Available PC): \u003C4 W
Security features	Kensington Lock
Power requirements	Input voltage 90 – 264 / 100 – 240 VAC, 50/60 Hz, 47 – 63 Hz, active PFC optional (External 80% High Efficiency) Operating Voltage Range: 90 – 264 VAC; Rated Voltage Range: 100 – 240 VAC; Rated Line Frequency: 50/60 Hz; Operating Line Frequency Range: 47 – 63 Hz; Rated Input Current 80 Plus: 2.5 A; Current Leakage (NFPA 99): \u003C 275 µA; System Heat Dissipation 80 Plus: Typical 315 btu/hr (79 kg-cal/hr), Maximum 1575 btu/hr (397 kg-cal/hr; Power Supply Fan: Variable speed fan, Power Consumption in ES Mode – Suspend to RAM (S3) (Instantly Available PC): \u003C4 W
External drive bays	2x 5.25\
Networking features	Gigabit Ethernet
Video card features	3D/2D Controller: support is fully compliant with Microsoft standard API such as Microsoft DirectX9, DirectXVA, VMR9, GDI/GDI+; OpenGL 1.4.; Integrated VGA Controller; integrated 350 MHz RAMDAC; 400 MHz Controller Clock Speed; Overlay Planes: Single overlay support with 5x3 filtering; Maximum Color Depth: 32 bits/pixel; Multi-display Support: 2 displays can be supported via the motherboard's VGA connectors and SDVO/ADD2 option Intel Graphics Media Accelerator 3100 \u003C85 Hz @ 1920x1440, 75 Hz @ 2048x1536
Acoustic power emissions	IDLE (Fixed disk drive spinning): LWAd = 3.8 Bels; FIXED DISK (Random write): LWAd = 3.9 Bels
Non-operating relative humidity (non-condensing)	5 - 90 %
Bundled software	On some models only (not included with FreeDOS): HP ProtectTools Security Solutions, HP Backup and Recovery Manager, HP Insight Diagnostics (available via HP Backup and Recovery Manager), HP Software Agent, HP Total Care Advisor, HP Client Configuration Manager, HP Client Manager for Altiris, HP SoftPaq Download Manager, HP Client Catalog for Microsoft SMS, HP Systems Software Manager, Computer Setup Utility, Altiris Out-of-Band Management Solution, McAfee AntiVirus trial version, Roxio DigitalMedia Plus 7.2/Easy Media Creator 9 Optional preloaded software, only for certain configurations: PDF Complete, Computrace for Desktops, Verdiem Surveyor agent, InterVideo WinDVD 5.0, Microsoft Office 2007 Basic, Microsoft Office 2007 Professional, Microsoft Office 2007 Small Business, Microsoft Internet Explorer with AOL Toolbar
Applications supported	Windows Vista Premium ready
Operating system installed	Windows Vista Business
Compatible operating systems	FreeDOS
Optional operating system supplied	Windows XP Professional
I/O ports	Rear: 6 USB 2.0, 1 serial port, 1 optional serial port, 1 optional parallel port, 2 PS/2, 1 RJ-45, 1 VGA, audio in/out; Front: 2 USB 2.0, audio ports
Serial ports quantity	1
USB 2.0 ports quantity	8
Parallel ports quantity	0
Chassis type	Micro Tower
Country of origin	China
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 9144 m
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Discrete graphics card model	Intel® GMA 3100
Maximum graphics card memory	0.256 GB
On-board graphics card model	Not available
Power consumption (typical)	300 W
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm

Weight and Dimensions

Depth	428 mm
Width	176 mm
Height	377 mm
Weight	8900 g
Package weight	4450 g
