HP Compaq Elite 8100 CMT User Manual

Intel HD Graphics
Intel HD GraphicsIntel HD Graphics
Intel HD Graphics
3D/2D Controller
3D/2D Controller3D/2D Controller
3D/2D Controller Microsoft DirectX® 10 based with support for Pixel Shader 3.0
VGA Controller
VGA ControllerVGA Controller
VGA Controller Integrated
DisplayPort
DisplayPortDisplayPort
DisplayPort Integrated, Multimode capable; supports HDCP
Bus Type
Bus TypeBus Type
Bus Type PCI Express™ x16
RAMDAC
RAMDACRAMDAC
RAMDAC Integrated, 350 MHz
Memory
MemoryMemory
Memory
Graphics memory is shared with system memory. Graphics memory usage varies depending on the
amount of system memory installed, BIOS settings, operating system, and system load. 32 MB is pre-
allocated for graphics use at system boot time. Additional memory can be allocated at boot time by the
BIOS for PAVP (Protected Audio Video Playback) support for playback of protected video content. For
Vista, use of PAVP heavy mode preallocates an additional 96MB.
Additional memory is allocated for graphics as needed using Intel's Dynamic Video Memory Technology
(DVMT), to provide an optimal balance between graphics and system memory use.
Windows XP Memory
Windows XP MemoryWindows XP Memory
Windows XP Memory
Usage
UsageUsage
Usage
Total System Memory Pre-Allocated (MB) DVMT (MB)
.5GB 32 128
1.0GB 32 512
1.5GB 32 768
2.0GB & more 32 1024
Assumes Management Engine, VT-d enabled and other memory allocated for other BIOS usage
Windows XP Memory
Windows XP MemoryWindows XP Memory
Windows XP Memory
Usage
UsageUsage
Usage
System
Memory
PVAP
Avail System
Memory (MB)
Total Avail
GFX Memory
(MB)
Dedicated
Video Memory
(MB)
System Video
Memory (MB)
Shared System
Memory (MB)
1 GB
Lite 952 252 32 96 124
Heavy 856 294 122 6 166
2 GB
Lite 1976 764 32 96 636
Heavy 1880 806 122 6 678
4 GB
Lite 4024 1759 32 96 1631
Heavy 3928 1759 122 6 1631
6 GB
Lite 6072 1759 32 96 1631
Heavy 5976 1759 122 6 1631
8 GB
Lite 8120 1759 32 96 1631
Heavy 8024 1759 122 6 1631
HW Video Decode
HW Video DecodeHW Video Decode
HW Video Decode
Hardware Accelerated decode for MPEG2 encrypted video; support for PAVP Lite (default) and Heavy ( or
Paranoid) modes
Maximum Color Depth
Maximum Color DepthMaximum Color Depth
Maximum Color Depth 32 bits/pixel
Maximum Vertical
Maximum VerticalMaximum Vertical
Maximum Vertical
Refresh Rate
Refresh RateRefresh Rate
Refresh Rate
85 Hz at up to 1920x1440, 75 Hz at 2048x1536. Varies with mode and configuration. See table below.
Multi-display Support
Multi-display SupportMulti-display Support
Multi-display Support
Integrated dual independent monitor support facilitated via one VGA port and one DisplayPort integrated
on the back plane of the system board and presented as part of the rear I/O set of interfaces. DVI
supported via optional HP DisplayPort to DVI-D adapter.
Graphics/Video API
Graphics/Video APIGraphics/Video API
Graphics/Video API
Support
SupportSupport
Support
Microsoft DirectX® 10, OpenGL® 1.5 (OpenGL® 2.0 available in a driver update)
Maximum Refresh Rate (Hz)
Maximum Refresh Rate (Hz)Maximum Refresh Rate (Hz)
Maximum Refresh Rate (Hz)
QuickSpecs
HP Compaq 8100 Elite Series
HP Compaq 8100 Elite SeriesHP Compaq 8100 Elite Series
HP Compaq 8100 Elite Series
Technical Specifications - Graphics
DA - 13524 North America — Version 20 — January 18, 2011 Page 33
