Hard drive
NOTE: The hard drive spare part kit does not include the hard drive bracket, hard drive connector
cable, or screws.
Description Spare part number
640-GB, 5400-rpm, 9.5-mm 669300-001
500-GB, 5400-rpm, 9.5-mm 669299-001
320-GB, 5400-rpm, 9.5-mm 622643-001
Hard Drive Hardware Kit (includes hard drive bracket, hard drive connector cable, and screws) 686261-001
Before removing the hard drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4.
Remove the battery (see
Battery on page 34).
5. Remove the memory module/wireless module compartment cover (see
Memory module
on page 35).
Remove the hard drive:
1. Loosen the captive screw (1) that secures the hard drive compartment cover to the computer.
2.
Lift the rear edge of the hard drive compartment cover (2) up and forward until it rests at
an angle.
44 Chapter 4 Removal and replacement procedures
