English 11
HP 15” Color Monitor User’s Guide
Technical Specifications
Technical Specifications
PICTURE TUBE
Size 15-inch flat screen/ 13.7-inch viewable image
Phosphorous Red, Green, Blue P22 (medium short persistence)
Dot pitch 0.28 mm
Face Plate Anti-glare, anti-static, screen coating
INPUT SIGNAL
Video 0.7 Vp p analog RGB
Synchronization TTL level separate synchronisation (negative/positive)
INTERFACE
Input Connector 15-pin mini D-SUB
SCANNING FREQUENCY
Horizontal 31 to 54kHz
Vertical 50 to 120 Hz
WARM-UP TIME
30 minutes to reach optimum performance level
PIXEL CLOCK
65 MHz
DISPLAY SIZE
270
×
202mm
±
3mm
POWER SOURCE
AC 90 to 264 V, 47 to 63 Hz, 90W (max), less than 15 W in Suspend mode, less than 8W in Sleep mode,
OPERATING ENVIRONMENT
Temperature 0
°
C to 40
°
C (operating)
- 25
°
C to +70
°
C (storage)
Humidity 10% RH through 80% RH (without condensation)
CABINET DIMENSIONS
396(H)
×
372(W)
×
396(D) mm (including pedestal)
WEIGHT
13 kg
TILT/SWIVEL STAND
Tilt Angle - 5
°
to +15
°
Swivel Angle
±
90
°
kiska1.bk : kiska-us.fb4 Page 11 Wednesday, April 22, 1998 9:22 PM
