18. Remove the wireless antenna transceivers and cables (4) from the display enclosure.
Reverse this procedure to reassemble and install the standard display assembly.
Flush Glass display assembly
1. If it is necessary to replace the Flush Glass display enclosure or any of the replaceable Flush Glass
display assembly components, remove the following screw covers (1) and screws (2):
2. Turn the display assembly over.
3. Slide the display enclosure toward the bottom edge of the assembly (1), and lift up to detach (2).
18 Chapter 1 Removal and replacement procedures ENWW
