HP E22 G4 User Manual

9
How to order parts
The HP authorized repair center can purchase the adaptor from HP.
Power board
Description
HP spare part number
Manufacturer part number
E22 G4
M97943-001
PLPCJB541IQA2
E22 G4
M97944-001
PLPCJB391GQA3
E22 G4
M97945-001
PLPCJB631IQA4
Capacitors and connectors are available for purchase from the following EU distributors:
 Farnell: Farnell UK - Electronic Components Distributor
 RS Component: Capacitors | RS Components (rs-online.com)
 DK : https://www.digikey.com/
Capacitors by distributor
Component
description
Location
Component
distributor
Distributor part
number
470uF 20% 25V 10*12.5
5000hr 1450mA
C904
RS
EEUFR1E471
470uF 20% 25V 10*12
10000hr 1.7A P5.0
C916
RS
NRZJ471M25V10X12.5F
Connectors by manufacturer
Component
description
Location identifier
Component distributor
Distributer part
number
USB 3.0 TYPE A R/A 18P
H16.42MM
CN103
DK
WM10420-ND
(0484060003)
USB 3.0 TYPE B
CN7732
DK
732-3158-ND
（692221030100）
14
RELEASE BUTTON
1
15
KEY BOARD
1
16
KEY BUTTON
1
17
REAR COVER
1
18
HP LOGO
1
19
SPEAKER COVER
1
20
STAND
1
21
BASE
1
S1
SCREW M3 X6
5
S2
SCREW M4 X6
1
S3
SCREW M3 X4
11
S4
SCREW Q3 X4
3
S5
SCREW M4 X4
4

HP E22 G4 Specifications

General

Color gamut	72 %
Pixel pitch	0.247 x 0.247 mm
Screen shape	Flat
Pixel density	94 ppi
Display diagonal	21.5 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Viewable size, vertical	267.7 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewable size, horizontal	476 mm
Digital vertical frequency	50 - 60 Hz
Digital horizontal frequency	30 - 80 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI version	1.4
DisplayPort version	1.2
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
Number of USB Type-B upstream ports quantity	1
Sustainability certificates	ENERGY STAR
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 23 °
Panel mounting interface	100 x 100 mm
Package depth	350 mm
Package width	565 mm
Package height	211 mm
Package weight	7700 g
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
Energy efficiency scale	A to G
Power consumption (max)	50 W
Power consumption (standby)	0.5 W
Power consumption (typical)	23 W
Product color	Black, Silver
Market positioning	Business
Cables included	AC, DisplayPort, HDMI, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	200.7 mm
Width (with stand)	488.7 mm
Height (with stand)	480.6 mm
Weight (with stand)	5300 g
Depth (without stand)	47 mm
Height (without stand)	294.6 mm
Weight (without stand)	2880 g
