HP ENVY m6 User Manual

1 Product description
Category Description UMA
models
Discrete
touch
models
Discrete
non-touch
models
Product Name HP ENVY Notebook PC × × ×
Processors Intel™ Core™ i5-4200M 2.50-GHz (SC turbo up to 3.10-GHz)
processor (1600-MHz FSB, 3.0-MB L3 cache, dual core, 37 W)
Intel Core i5-4210M 2.60-GHz (SC turbo up to 3.20-GHz) processor
(1600-MHz FSB, 3.0-MB L3 cache, dual core, 37 W)
×
Intel Core i7-4712HQ 2.3-GHz (SC turbo up to 3.3-GHz) processor
(1600-MHz FSB, 6.0-MB L3 cache, 37 W
Intel Core i7-4722HQ 2.4-GHz (SC turbo up to 3.4-GHz) processor
(1600-MHz FSB, 6.0-MB L3 cache, 37 W
××
Chipset Intel HM87 express chipset × × ×
Graphics Intel graphics: Intel HD Graphics 4600
Support for HD decode, DX11, and HDMI
×
Discrete graphics: Nvidia N15P-GT (GTX 850M) with 4GB of
dedicated video memory
Support for HD decode, DX11, and HDMI
Supports Optimus
Supports GPS (GPU performance scaling)
××
Panel Support for low-voltage differential signalling LVDS, co-layout
with eDP1.3+PSR)
Touchscreen and MultiTouch enabled
Airgap bonding
×× ×
●
15.6-in, full high-definition (FHD), white light-emitting diode
(WLED), AntiGlare (1920×1080), slim (3.2-mm), SVA, color
gamut 60%, TN, typical brightness 300 nits, 16:9 aspect ratio
●
15.6-in, high-definition (HD), white light-emitting diode
(WLED), AntiGlare (1366×768), flat (3.8-mm), SVA, color
camut 45%, typical brightness 200 nits, 16:9 aspect ratio
×× ×
●
15.6-in, full high-definition (FHD), white light-emitting diode
(WLED), BrightView (1920×1080), slim (3.2-mm), SVA, color
gamut 60%, TN, typical brightness 300 nits, 16:9 aspect ratio
●
15.6-in, high-definition (HD), white light-emitting diode
(WLED), BrightView (1366×768), flat (3.8-mm), SVA, color
camut 45%, typical brightness 200 nits, 16:9 aspect ratio
×
Memory Two customer-accessible/upgradable memory module slots
Support for DDR3L (1600-MHz) dual channel
Support for 16834-MB of system RAM in the
following configurations:
×× ×
1

HP ENVY m6 Specifications

General

LED backlight	Yes
Display surface	Gloss
Display diagonal	15.6 \
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Bus type	DMI
Tjunction	105 °C
Processor cache	6 MB
Processor cores	4
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3600 Mobile series
Processor socket	Socket 1224
Processor threads	8
Processor codename	Ivy Bridge
Processor frequency	2.2 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	22
Maximum number of PCI Express lanes	16
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	1000 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Number of SSDs installed	0
On-board graphics card ID	0x166
Discrete graphics card model	AMD Radeon HD 7670M
On-board graphics card model	Intel® HD Graphics 4000
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR3
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	Beats Audio
Number of built-in speakers	2
Video capturing speed	30 fps
Data network	Not supported
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit LAN, WLAN
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Operating system installed	Windows 8
Form factor	Clamshell
Product type	Laptop
Product color	Silver
Country of origin	China
Processor ARK ID	71458
Processor package size	37.5 x 37.5 (rPGA988B) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery life (max)	- h
Number of battery cells	6
AC adapter power	90 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Operating altitude	-15 - 3048 m
Non-operating altitude	-15 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	250.7 mm
Width	379.5 mm
Height	26.5 mm
Weight	2400 g
