HP FlexFabric 10Gb 2-port 533FLR-T User Manual

Product Features Industry-leading throughput and latency performance
FlexibleLOM adapter
Operates at 1Gbps/10Gbps, auto-negotiation, on both ports
10GBASE-T connectivity supporting up to 100 meters with CAT 6A cabling
Up to 40Gb/s bi-directional near line rate throughput
Hardware acceleration TCP/IP/UDP stateless offloads, as well as for TCP Offload Engine (TOE)
Superior small packet performance
SR-IOV
Active Health Systems support
PXE, Jumbo Frames, Checksum & Segmentation Offload, IPv6 and RSS
On chip temperature monitor (Sea of Sensors)
Field replaceable and upgradeable
Support for Preboot eXecution Environment (PXE)
Network Partitioning
Dual-port 10 Gigabit
Ethernet Throughput
The HP 533FLR-T adapter delivers 20 Gbps full duplex Ethernet transfer rate per port , providing the
network performance needed to improve response times and alleviate bottlenecks that impact
performance of next generation data centers. 10Gb Ethernet bandwidth is ideal for high performance
computing, database clusters, and more.
Jumbo Frames The HP 533 FLR-T adapter supports jumbo frames (also known as extended frames), permitting up to a 9K
byte (KB) transmission unit (MTU) when running Ethernet I/O traffic. This is over 5X the size of a standard
1500-byte Ethernet frame. With jumbo frames, networks can achieve higher throughput performance and
improve CPU utilization. These attributes are particularly useful for database transfer and tape backup
operations.
TCP/IP Stateless
Offloading
TCP, IP, UDP checksum offload, Large Send Offload (LSO), TCP Segmentation Offload (TSO). These features
optimize host efficiency, leaving the CPU available for other duties.
The HP 533 FLR-T Adapter by Broadcom offers TCP/IP stateless offloading capability.
MSI and MSI-X Message Signaled Interrupt (Extended) provides performance benefits for multi-core servers by load
balancing interrupts between CPUs/cores. The HP 533 FLR-T Adapter by Broadcom supports MSI and MSI-
X.
802.1Q VLANs IEEE 802.1Q virtual local area network (VLAN) protocol allows each physical port of the HP 533 FLR-T
adapter to be separated into multiple virtual NICs for added network segmentation and enhanced security
and performance. VLANs increase security by isolating traffic between users. Limiting the broadcast traffic
to within the same VLAN domain also improves performance. The HP 530T Adapter by Broadcom provides
support for 802.1Q (VLAN).
TOE TCP/IP Offload Engine (TOE) shifts the processing of data in the TCP protocol stack from the server CPU to
the adapter's processor, freeing server CPU cycles for other operations.
QuickSpecs
HP FlexFabric 10Gb 2-port 533FLR-T Adapter
Standard Features
DA - 14616 North America — Version 2 — May 9, 2014 Page 3

HP FlexFabric 10Gb 2-port 533FLR-T Specifications

General

Ports	2
Connector	RJ-45
Network Protocols	iSCSI
Compatibility	HP ProLiant Gen8 and Gen9 servers
Data Transfer Rate	20Gbps (full-duplex)
Bus Type	PCIe 2.0 x8
Features	iSCSI
Port Speed	10 Gbps
Ports Description	2 x 10GbE ports

Summary

Overview

Models

Lists the specific HP FlexFabric 10Gb 2-port 533FLR-T Adapter models available.

Kit Contents

Details the items included in the package with the adapter.

Compatibility

ProLiant DL (rack-optimized) Servers

Lists HP ProLiant DL series servers compatible with the adapter.

ProLiant SL (scalable line) Servers

Lists HP ProLiant SL series servers compatible with the adapter.

Standard Features

Dual-port 10 Gigabit Ethernet Throughput

Describes the adapter's 20 Gbps full duplex Ethernet transfer rate per port.

Jumbo Frames

Explains support for jumbo frames up to 9K bytes for higher throughput.

TCP/IP Stateless Offloading

Details offloading capabilities for TCP, IP, UDP checksums to optimize host efficiency.

MSI and MSI-X

Covers Message Signaled Interrupt support for performance in multi-core servers.

802.1Q VLANs

Describes support for IEEE 802.1Q VLAN protocol for network segmentation.

TOE

Explains TCP/IP Offload Engine (TOE) function to free server CPU cycles.

Optimized for Virtualization

Highlights I/O virtualization support for VMware NetQueue and Microsoft VMQ.

Checksum & Segmentation Offload

Details adapter capabilities for computing TCP checksum and segmentation offload.

IPv6

Confirms support for IPv6 128-bit addressing.

Receive Side Scaling (RSS)

Explains RSS for sharing network load across multiple processors.

Time synchronization implementations (PTP)

Covers Precision Time Protocol (PTP) support for accurate clock synchronization.

Network Adapter Teaming

Describes NIC teaming for increased fault tolerance and network bandwidth.

Network Partitioning

Details NIC partitioning for creating separate virtual NIC ports from a physical port.

Server Integration

Discusses the adapter's validation and optimization for HP ProLiant servers.

Configuration Utilities

Highlights utilities for diagnostics, adapter teaming, and scripted installations.

LED Indicators

Explains the function of colored LEDs on each port for link status.

Preboot execution Environment (PXE)

Describes PXE functionality for booting over the network.

HP Sea of Sensors 3D

Covers support for HP Sea of Sensors 3D for thermal tracking and energy reduction.

VMware NetQueue and Microsoft Virtual Machine Queue (VMQ)

Details support for VMware NetQueue and VMQ for improved virtualized performance.
