HP L1706 User Manual

17" LCD Color Monitor HP L1706
4
2. LCD Monitor Description
The LCD Monitor will contain main board, power board, key board and an audio board which house the flat panel
control logic, brightness control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each
voltage.
Video signal, DDC
Power Board
(
Include ada
p
ter and inverter
)
Flat Panel and
CCFL backlight
Main Board
Audio board
RS232 Connector
For white balance
adjustment in
factory mode
HOST Computer
CCFT Drive.
AC-IN
110V-240
Monitor Block Diagram
Key board

HP L1706 Specifications

General

Plug and Play	Yes
Height adjustment	No
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
HD type	-
Panel type	TFT
Response time	8 ms
Display surface	Matt
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Display technology	LCD
Vertical scan range	50 - 76 Hz
Horizontal scan range	30 - 83 kHz
Viewing angle, vertical	130 °
Contrast ratio (typical)	500:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	140 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 832 x 624, 1024 x 768 (XGA), 1152 x 870
Active display area (W x H)	338 x 270 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	37 W
Power consumption (standby)	2 W
Power consumption (typical)	33 W
HDMI ports quantity	0
Product color	Silver
Country of origin	China
Market positioning	Business
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	203 mm
Height (with stand)	395 mm
Depth (without stand)	64 mm
Width (without stand)	375 mm
Height (without stand)	330 mm
Weight (without stand)	4600 g
