HP L1710 User Manual

17" LCD Color Monitor HP L1710
39
2. W/LED No Backlight
Check C812 (+) =12V
NG
OK
Check Q806
Check ON/OFF signal
Check Interface board
NG
OK
Check IC801 pin2=5V ?
NG
OK
Change Q802 or Q803
Check the pin1 of IC801 have saw tooth wave
NG
OK
Change IC801
Check ZD803 has the output of square wave at short time.
NG
O
CheckQ805/Q806
Check the resonant wave of pin2 & pin5 for T801
NG
Check the output of T801
Check Q801/Q811/D806/D807/D808
Check connecter & lamp
OK
NG
Change T801
OK

HP L1710 Specifications

General

3D	No
HD type	-
Panel type	TFT
Pixel pitch	0.264 x 0.264 mm
Display surface	Matt
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Display technology	LCD
Vertical scan range	50 - 77 Hz
Horizontal scan range	24 - 83 kHz
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA)
UNSPSC-code	43211902
On/off switch	Yes
Power requirements	100 - 240 VAC, 50 - 60 Hz
Display viewable area (HxV)	432 mm
HDMI ports quantity	0
Certification	ISO 13406-2 pixel defect guidelines, MPR-II, CISPR, VCCI, CSA(Canada), ACA (Australia), TUV and GS Mark (German ergonomic), BSMI (Taiwan), CCC (China), MIC (South Korea), NOM (Mexico), Eastern European approvals, CE Marking, FCC approval, TCO '03 (emissions, ergonomics, environment), Microsoft Windows certified (Microsoft Windows 2000, Microsoft Windows XP, and Windows Vista), UL listed, GOST (Russia), SASO (Saudi Arabia), Restrictions of Hazardous Substances (RoHS) Directive, 2002/95/EC, Waste Electrical and Electronic Equipment (WEEE) Directive, 2002/96/EC
Product color	Silver
Country of origin	China
Market positioning	Business
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	30 W
Operating temperature (T-T)	5 - 35 °C
Non-operating relative humidity (non-condensing)	5 - 90 %
Package weight	6100 g
Sustainability certificates	ENERGY STAR
Cables included	AC, VGA

Weight and Dimensions

Depth (with stand)	192 mm
Width (with stand)	377 mm
Height (with stand)	386 mm
Weight (with stand)	4700 g
Depth (without stand)	57 mm
Height (without stand)	316 mm
Weight (without stand)	3920 g
