9.2 Trouble Shooting
9.2.1 Main Board
1、No power
No power
Press power key and look if the
picture is normal
Please reinsert and make sure the
AC of 100-240 is normal
Reinsert or check the
power section
X201 oscillate waveforms are
normal
Measure U701 PIN 2=3.3V
Q403 = 3.3V
Measure CN401 PIN5/6=5V?
Replace U401
Replace X201
OK
OK
OK
NG
NG
NG
NG
Chec
TXD
Check power section
Replace U701/Q403

HP L1950 Specifications

General

3D	No
HD type	-
Panel type	TFT
Display surface	Matt
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Display technology	LCD
Vertical scan range	50 - 77 Hz
Horizontal scan range	24 - 83 kHz
Contrast ratio (typical)	800:1
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 832 x 624, 1024 x 768 (XGA), 1152 x 870
Plug and Play	Yes
Tilt angle range	-5 - 35 °
Active display area (W x H)	378 x 303 mm
AC input voltage	90 - 256 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	30 W
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	2
Product color	Silver
Country of origin	China

Weight and Dimensions

Bezel width (top)	18 mm
Depth (with stand)	301 mm
Height (with stand)	503 mm
Weight (with stand)	7400 g
Bezel width (bottom)	27 mm
Depth (without stand)	58 mm
Width (without stand)	414 mm
Height (without stand)	347 mm
Weight (without stand)	6500 g
