HP Omen series User Manual

2. Remove the plastic plug and screw (1), and then remove the 2 Phillips M2x5.0 screws (2) and the 8
M2.5x6.0 screws (3).
NOTE: There are three internal clips by the battery area. Carefully disengage those clips as you are
removing the base enclosure.
3. Slide a nylon ake tool around the edge of the base enclosure to loosen it, taking care not to damage
the internal clips. Lift the front edge (1) to access the internal clips in the battery area.
4. Remove the base enclosure (2).
Reverse this procedure to replace the base enclosure.
Component replacement procedures 33

HP Omen series Specifications

General

Brand	HP
Model	Omen series
Category	Laptop
Language	English
