Hard drive
NOTE: The hard drive spare part kit does not include the hard drive bracket, connector cable,
isolators, or screws. These components are included in the Hard Drive Hardware Kit, spare part
number 664913-001.
Description Spare part number
640-GB, 5400-rpm, SATA, 7.0-mm 603785-001
500-GB, 7200-rpm, SATA, 7.0-mm 634925-001
320-GB, 7200-rpm, SATA, 7.0-mm 634862-002 and
641672-001
For use only with computer models equipped with an AMD processor and with WWAN capability:
640-GB, 5400-rpm, SATA, 7.0-mm 669300-001
500-GB, 5400-rpm, SATA, 7.0-mm 669299-001
Before removing the hard drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the service door (see
WLAN module on page 48).
Remove the hard drive:
1. Disconnect the hard drive connector cable (1) from the system board.
2. Remove the Phillips PM2.5×5.7 screw (2) that secures the hard drive to the computer.
3. Use the tab (3) on the hard drive bracket to lift the left side of the hard drive until it rests at
an angle.
Component replacement procedures 55
