HP Pavilion dv1000 User Manual

Removal and Replacement Procedures
Maintenance and Service Guide 5–57
4. Turn the top cover upside down with the front panel
toward you.
✎
Steps 5 and 6 apply only to HP Pavilion dv1000 models. See
steps 7 and 8 in this section for information on removing the
system board on HP Compaq nx4800 and Compaq Presario
V2000 models.
5. Release the ZIF connector 1 to which the LED board cable is
connected and disconnect the cable 2 from the system board.
6. Remove the four PM2.0×4.0 screws 3 that secure the system
board to the top cover.
Disconnecting the LED Board Cable and Removing the System
Board Screws, HP Pavilion dv1000 models Only
