Sequential part number listing

Spare part number Description

449137-001 RTC battery

490371-001 Power cord for use in North America (for use with all computer models; 3-pin, black, 1.83-m)

490371-061 Power cord for use in Italy (for use only with computer models equipped with an Intel processor;

3-pin, black, 1.83-m)

490371-202 Power cord for use in Brazil (for use only with computer models equipped with an Intel processor;

3-pin, black, 1.83-m)

490371-D01 Power cord for use in Argentina (for use only with computer models equipped with an

Intel processor; 3-pin, black, 1.83-m)

531993-001 HP un2420 EV-DO/HSPA Mobile Broadband Module (for use only with computer models

equipped with an Intel processor)

572520-001 Intel Centrino Wireless-N 1000 802.11b/g/n 1×2 WLAN module (for use only with computer

models equipped with an Intel processor)

593127-001 Atheros AR9002WB-1NGB 802.11b/g/n 1×1 WiFi and Bluetooth 2.1+EDR Combo Adapter

(BT3.0+HS ready)

593554-001 6-cell, 55-Whr, 2.55-Ah Li-ion battery

593562-001 6-cell, 62-Whr, 2.80-Ah Li-ion battery

602993-001 Realtek 8188BC8 802.11a/b/g/n 2×2 WiFi and Bluetooth 3.0+HS Combo Adapter

609939-001 65-W RC V 3-wire HP Smart AC adapter

609940-001 90-W PFC RC V 3-wire HP Smart AC adapter

621046-001 640-GB, 7200-rpm, 7.0-mm, SATA hard drive (does not include hard drive connector cable, hard

drive bracket, or screws)

621565-001 2-GB memory module (PC3, 10600, 1333-MHz)

621569-001 4-GB memory module (PC3, 10600, 1333-MHz)

630703-001 Ralink 5390GN 802.11b/g/n 1×1 WiFi Adapter

631253-001 Intel Core i5-2540M 2.60-GHz (SC turbo up to 3.30-GHz) processor (3.0-MB L3 cache,

Dual Core, 35 W; includes replacement thermal material)

631255-001 Intel Core i5-2520M 2.50-GHz (SC turbo up to 3.20-GHz) processor (3.0-MB L3 cache,

Dual Core, 35 W; includes replacement thermal material)

631956-001 Intel Centrino Advanced-N 6230 WLAN module (for use only with computer models equipped

with an Intel processor)

632155-001 HP hs2340 HSPA+ Mobile Broadband Module (for use only with computer models equipped with

an Intel processor)

633252-001 750-GB, 7200-rpm, 7.0-mm, SATA hard drive (does not include hard drive connector cable, hard

drive bracket, or screws)

634250-001 750-GB, 5400-rpm, 7.0-mm, SATA hard drive (does not include hard drive connector cable, hard

drive bracket, or screws)

Sequential part number listing
