HP PAVILION G6 User Manual

on the drivers and software installed on your computer, you may need slightly more than 8 GB of
space. HP recommends that you use a 16 GB device or above for best results.
IMPORTANT: Remember to insert your USB device into the USB port on the computer before starting
this procedure.
To create the restore image:
1. Click the System menu icon at the far right of the top panel, and then click System Settings
> Backup.
2.
Select Storage from the panel on the left side of the window, click the down-arrow next to
Backup location, and select the USB device from the drop-down list.
NOTE: If the USB device is not listed in the drop-down list for Backup Location, select Local
Folder, and then click the Choose Folder button. Select the USB device from the panel on the
left side of the Choose Folder window, and click OK.
3. Select Overview from the panel on the left side of the window, and then click Backup Now.
4. Follow the on-screen instructions.
Performing recovery using the restore DVD
NOTE: The following procedure uses the F11 BIOS Recovery feature to perform the recovery.
1. If possible, back up all personal files.
2. Shut down the computer.
3. Be sure the restore DVD or USB device is connected to the computer.
4. Restart the computer.
5.
Using the arrow keys, select Recovery, and then press enter.
6. Follow the on-screen instructions.
NOTE: If you are unable to boot (start up) your computer, and you did not create a system recovery
disc, you must purchase an Ubuntu Operating System DVD to reinstall the operating system. For
additional information, refer to the Worldwide Telephone Numbers booklet.
Backing up your information
You should back up your computer files on a regular schedule to maintain a current backup. You can
manually back up your information to an optional external drive, a network drive, discs, or the Ubuntu
One website. Back up your system at the following times:
●
At regularly scheduled times
●
Before the computer is repaired or restored
●
Before you add or modify hardware or software
To back up your home directory files to the Ubuntu One website using the Deja Dup Backup Tool:
ENWW
Backing up your information
109

HP PAVILION G6 Specifications

General

Processor cache	2 MB
Processor cores	4
Processor model	P960
Processor family	AMD Phenom II
Processor socket	Socket S1
Processor frequency	1.8 GHz
Processor cache type	L2
Processor manufacturer	AMD
Number of processors supported	1
Motherboard chipset	-
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	1 x 4 GB
Type	PC
Power supply type	AC/DC
Infrared data port	No
Number of speakers	2
AC adapter included	Yes
Ethernet interface type	Fast Ethernet
Number of products included	1 pc(s)
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Display diagonal (metric)	39.6 cm
Discrete graphics card model	AMD Radeon HD 6470M
On-board graphics card model	Not available
Discrete graphics memory type	GDDR3
Speakers manufacturer	Altec Lansing
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Networking features	Fast Ethernet, WLAN
Ethernet LAN data rates	10, 100 Mbit/s
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Home Basic
Operating system architecture	64-bit
Form factor	Clamshell
Product color	Gray
Country of origin	China
Battery life (max)	- h
Number of battery cells	6
AC adapter power	90 W

Weight and Dimensions

Depth	245 mm
Width	374 mm
Height	30.5 mm
Weight	2550 g
