General| Bus type | DMI |
|---|---|
| Stepping | C2 |
| Tjunction | 105 °C |
| Processor cache | 3 MB |
| Processor cores | 2 |
| Processor model | i3-330M |
| System bus rate | 2.5 GT/s |
| Processor family | Intel® Core™ i3 |
| Processor series | Intel Core i3-300 Mobile Series |
| Processor socket | BGA 1288 |
| Processor threads | 4 |
| Processor codename | Arrandale |
| Processing Die size | 81 mm² |
| Processor frequency | 2.13 GHz |
| Processor cache type | Smart Cache |
| Processor lithography | 32 nm |
| Processor manufacturer | Intel |
| Processor front side bus | - MHz |
| PCI Express slots version | 2.0 |
| Processor operating modes | 64-bit |
| ECC supported by processor | No |
| PCI Express configurations | 1x16 |
| Thermal Design Power (TDP) | 35 W |
| Maximum number of PCI Express lanes | 16 |
| Number of Processing Die Transistors | 382 M |
| Motherboard chipset | Intel® HM57 Express |
| HDD speed | 7200 RPM |
| HDD interface | SATA II |
| Optical drive type | DVD Super Multi DL |
| Card reader integrated | Yes |
| Total storage capacity | 320 GB |
| Display diagonal | 15.6 \ |
| Display resolution | 1366 x 768 pixels |
| Native aspect ratio | 16:9 |
| Memory slots | 2x SO-DIMM |
| Internal memory | 3 GB |
| Memory clock speed | 1333 MHz |
| Internal memory type | DDR2-SDRAM |
| Memory layout (slots x size) | 1 x 1 + 1 x 2 GB |
| Discrete graphics card model | AMD Mobilty Radeon HD 4330 |
| On-board graphics card model | Intel® HD Graphics |
| Discrete graphics card memory | 0.512 GB |
| On-board graphics card base frequency | 500 MHz |
| On-board graphics card dynamic frequency (max) | 667 MHz |
| Type | PC |
| Wireless technology | 802.11b/g/n |
| Intel segment tagging | Enterprise |
| Audio system | HD |
| Bluetooth version | 2.1+EDR |
| Networking features | Gigabit Ethernet |
| Trial software | Corel Home Office; Microsoft Office Professional 2007; WinZip 12; |
| Operating system installed | Windows 7 Professional |
| Battery life (max) | 5 h |
| Number of battery cells | 6 |
| Charging port type | DC-in jack |
| Serial ports quantity | 0 |
| USB 2.0 ports quantity | 3 |
| Sustainability certificates | ENERGY STAR |
| Processor code | SLBNF |
| Processor ARK ID | 47663 |
| Processor package size | rPGA 37.5x 37.5, BGA 34x28 mm |
| Graphics & IMC lithography | 45 nm |
| Supported instruction sets | SSE4.1, SSE4.2 |
| Country of origin | China |
Weight and Dimensions| Depth | 249.6 mm |
|---|---|
| Width | 371.8 mm |
| Weight | 2390 g |
| Height (front) | 27.7 mm |
Details various Intel Core and Pentium processors compatible with the models.
Lists the Intel HM57 Express chipset used in the computers.
Describes Intel HD Graphics and ATI Mobility Radeon options.
Lists available 15.6-in and 17.3-in HD LED backlight display panel options.
Details memory module types, slots, speed, and supported configurations.
Specifies supported hard drive sizes, interface, and accessibility.
Lists supported optical drive types like DVD-ROM and DVD±RW.
Details audio components like speakers, microphone, and camera.
Describes modem options, including availability and cable status.
Lists Ethernet interface specifications and wake-on-LAN support.
Covers WLAN and WWAN modules, including supported formats and antennas.
Details support for ExpressCard/34 mm and Media Card Reader formats.
Lists available ports like Audio-in, Audio-out, USB, HDMI, etc.
Describes keyboard and Clickpad features for different display sizes.
Specifies AC adapter wattages and battery type.
Mentions Kensington security lock support.
Details fingerprint reader availability for different display sizes.
Lists preinstalled Microsoft Office versions and operating systems.
Lists end-user replaceable parts like AC adapter, battery, hard drive, etc.
Identifies and describes the TouchPad, its indicator light, and other top-mounted elements.
Identifies and describes the drive light, media card reader, and audio jacks.
Identifies USB ports, RJ-11 jack, optical drive, AC adapter light, and power connector.
Identifies security slot, vent, external monitor port, and RJ-45 network jack.
Identifies battery latches, battery bay, and SIM slot.
Identifies internal display switch, microphone, webcam light, and webcam.
Identifies WWAN and WLAN antennas and their functions.
Identifies the power cord, battery, and AC adapter.
Explains the components of the service tag for identification and ordering.
Lists major internal components like display assembly, switch cover, keyboard, and system board.
Lists various display assemblies for 17.3-in and 15.6-in models, including trim and features.
Lists components included in the Plastics Kit and its part number.
Lists Base Cable Kit and Misc LCD Cable Kit part numbers.
Lists part numbers for hard drives and optical drives.
Lists AC adapters, power cords, screw kits, and rubber kits.
Provides a comprehensive list of part numbers categorized by component and region.
Covers essential tools, service considerations, and handling precautions.
Explains ESD prevention, workstation, packaging, and equipment grounding guidelines.
Details the process for replacing major computer components.
Step-by-step instructions for removing and installing the computer battery.
Provides procedures for removing the switch cover and keyboard assembly.
Instructions for removing and installing memory modules.
Detailed steps for removing and installing the optical drive.
Instructions for removing and installing the power button board.
Details the procedures for removing and installing the computer speakers.
Provides instructions for removing and installing the thermal shield.
Lists processor part numbers and provides removal/installation instructions.
Lists palm rest part numbers and provides removal/installation instructions.
Details procedures for removing and installing the hard drive.
Provides instructions for removing the display assembly for 17.3-in models.
Provides instructions for removing the display assembly for 15.6-in models.
Provides instructions for removing the top cover, with differences for 17.3-in and 15.6-in computers.
Provides instructions for removing and installing the RTC battery.
Lists Bluetooth module part numbers and provides removal/installation instructions.
Lists modem module part numbers and provides removal/installation instructions.
Lists audio board part numbers and provides removal/installation instructions.
Lists system board part numbers and provides removal instructions.
Lists USB connector assembly part numbers and provides removal/installation instructions.
Lists RJ-11 connector assembly part numbers and provides removal/installation instructions.
Lists power connector assembly part numbers and provides removal/installation instructions.
Explains how to access and start the Computer Setup utility.
Guides users on navigating and selecting options within Computer Setup.
Details how to reset Computer Setup settings to factory defaults.
Overview of File, System Diagnostics, Restore Defaults, and BIOS security options.
Covers BIOS passwords, user accounts, SpareKey, DriveLock, Disk Sanitizer, and System IDs.
Configures language, boot options, device settings, ports, AMT, and security levels.
Details dimensions, weight, power, temperature, humidity, and altitude for the computer.
Provides dimensions, color, contrast, brightness, resolution, and response time for 17.3-in displays.
Provides dimensions, color, contrast, brightness, resolution, and response time for 15.6-in displays.
Details dimensions, interface, transfer rate, security, seek times, and operating temperature.
Lists applicable discs, access times, cache buffer, and data transfer rates.
Lists applicable discs, access times, cache buffer, and data transfer rates for reading and writing.
Lists applicable discs, access times, cache buffer, and data transfer rates.
Explains using Backup and Restore Center for data protection and recovery.
Guides on using Windows recovery tools, f11, and Windows 7 OS DVD for system recovery.
Explains using Backup and Restore Center for data protection and recovery in Vista.
Guides on using Windows recovery tools, f11, and Vista OS DVD for system recovery.
Explains using Windows Backup utility for file backup and recovery points.
Guides on using Windows Backup utility and recovery discs for system restoration.
Details pin assignments for the audio-in (microphone) connector.
Details pin assignments for the audio-out (headphone) connector.
Details pin assignments for the external monitor connector.
Details pin assignments for the HDMI connector.
Details pin assignments for the RJ-11 (modem) connector.
Details pin assignments for the RJ-45 (network) connector.
Details pin assignments for the Universal Serial Bus (USB) connector.
Details general requirements for power cord length, approval, capacity, and appliance coupler.
Lists accredited agencies and notes for power cord requirements by country/region.
Provides guidelines for proper battery disposal at the end of its life.
Warns about mercury in the backlight and provides disposal guidelines.
Step-by-step instructions for disassembling the display assembly, starting with the bezel.
