HP ProCurve Switch 1800 Series
3
Specifications
HP ProCurve Switch 1800-8G (J9029A) HP ProCurve Switch 1800-24G (J9028B)
Ports
8 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T, IEEE
802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Media
Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full;
1000Base-T: full only
22 auto-sensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T,
IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T);
Media Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full;
1000Base-T: full only
2 dual-personality ports; each port can be used as either an RJ-45
10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type
100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an
open mini-GBIC slot (for use with mini-GBIC transceivers)
Physical characteristics
Dimensions
4.58(d) x 7.73(w) x 1.73(h) in. (11.63 x 19.63 x 4.39 cm) (1U height) 6.74(d) x 17.42(w) x 1.73(h) in. (17.12 x 44.25 x 4.39 cm) (1U height)
Weight
1.19 lb. (0.54 kg), Fully loaded 4.32 lb. (1.96 kg), Fully loaded
Memory and processor
1 MB flash, 64 KB SDRAM, 1 MB RAM/ROM capacity; packet buffer
size: 144 KB
2 MB flash, 64 KB SDRAM, 2 MB RAM/ROM capacity; packet buffer
size: 500 KB
Mounting
Horizontal surface mounting only Mounts in an EIA-standard 19 in. telco racks (hardware included)
Performance
100 Mb Latency
< 3.9 µs (64-byte packets) < 4.7 µs (64-byte packets)
1000 Mb Latency
< 2.1 µs (64-byte packets) < 3.0 µs (64-byte packets)
Throughput
up to 11.9 million pps (64-byte packets) up to 35.7 million pps (64-byte packets)
Switching capacity
16 Gbps 48 Gbps
MAC address table size
8000 entries 8000 entries
Environment
Operating temperature
32ºF to 104ºF (0ºC to 40ºC) 32ºF to 104ºF (0ºC to 40ºC)
Operating relative humidity
10% to 90% @ 104ºF (40ºC), non-condensing 10% to 90% @ 104ºF (40ºC), non-condensing
Non-operating/Storage temperature
-40ºF to 158ºF (-40ºC to 70ºC) -40ºF to 158ºF (-40ºC to 70ºC)
Non-operating/Storage relative humidity
10% to 90% @ 149ºF (65ºC), non-condensing 10% to 90% @ 149ºF (65ºC), non-condensing
Altitude
up to 10000 ft. (3 km) up to 10000 ft. (3 km)
Acoustic
Power: 0 dB no fan Power: 0 dB no fan
Electrical characteristics
Maximum heat dissipation
61 BTU/hr (64 kJ/hr) 92 BTU/hr (97 kJ/hr)
Voltage
100-240 VAC 100-127 / 200-240 VAC
Current
0.5 A 0.8 / 0.4 A
Power consumption
18 W 27 W
