HP 750W Common Slot Gold Hot Plug Factory Integrated Power Supply Kit with Backplane
Part Number
535683-B21 Option Kit
Input Voltage Range (Vrms)
100 to 240
Frequency Range (Nominal) (Hz)
50/60
Nominal Input Voltage (Vrms)
100 120 200 208 220 230 240
Maximum Rated Output Wattage
Rating
750 750 750 750 750 750 750
Nominal Input Current (A rms)
8.9 7.4 4.3 4.1 3.9 3.7 3.6
Maximum Rated Input Wattage
Rating (Watts)
857 847 824 825 820 820 820
Maximum Rated VA (Volt-Amp)
894 884 859 859 854 854 854
Efficiency (%)
87.5 88.5
91 91
91.5 91.5 91.5
Power Factor
0.97
Leakage Current (mA)
0.42 0.50 0.83 0.87 0.92 0.96 1.00
Maximum Inrush Current (A peak)
30
Maximum Inrush Current duration
(mS)
20
Maximum British Thermal Unit
Rating (BTU-Hr)
2925 2892 2812 2812 2797 2797 2797
HP 500W Factory Integrated Power Supply Kit
Part Number
515915-B21 Option Kit
Input Voltage Range (Vrms)
100 to 240
Frequency Range (Nominal) (Hz)
47/63
Nominal Input Voltage (Vrms)
100 120 200 220 230 240
Maximum Rated Output Wattage
500 500 500 500 500 500
Nominal Input Current (A rms)
5.74 4.99 2.86 2.58 2.46 2.36
Maximum Rated Input Wattage
Rating (Watts)
568 568 562 556 556 556
Maximum Rated VA (Volt-Amp)
574 574 573 567 567 567
Efficiency (%)
88 88 89 90 90 90
Power Factor
0.99 0.99 0.98 0.98 0.98 0.98
Leakage Current (mA)
0.42 0.50 0.81 0.91 0.95 1.00
Maximum Inrush Current (A peak)
30
Maximum Inrush Current duration
(mS)
20
Maximum British Thermal Unit
Rating (BTU-Hr)
QuickSpecs
HP ProLiant DL160 Generation 6 (G6)
Power Specifications
DA - 13247 North America — Version 59 — September 24, 2012
Page 49
