HP ProLiant ML110 Generation 5 (G5) User Manual

NOTE:
NOTE:NOTE:
NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO
product offerings and requirements.
NOTE:
NOTE:NOTE:
NOTE: HP does not allow factory integration of options into standard models listed above.
Configure-to-order servers must start with a CTO Chassis.
NOTE:
NOTE:NOTE:
NOTE: FIO indicates that this option is a Factory Installable Option.
Step 1: Base Configuration
Step 1: Base ConfigurationStep 1: Base Configuration
Step 1: Base Configuration
Models
ModelsModels
Models HP ProLiant ML110G5 NHP CTO Chassis 445607-B21
Factory Integrated Models ship with:
Factory Integrated Models ship with:Factory Integrated Models ship with:
Factory Integrated Models ship with:
Embedded NC105i PCI Express Gigabit Ethernet Server Adapter
Keyboard and Mouse
NOTE:
NOTE:NOTE:
NOTE: Keyboard and Mouse option needs to be manually selected for shipment.
Please see the USB Options listed in the options selection of this QuickSpecs.
Power cord
Micro ATX Tower (4U)
NOTE:
NOTE:NOTE:
NOTE: HP SATA drive models are limited to 4.0TB support.
NOTE:
NOTE: NOTE:
NOTE: On SATA models with embedded RAID, setup instructions are located in the
User Guide. CTO RAID set-up is not available. HP ProLiant ML100 Series Server User
Guide:
http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00260539/
c00260539.pdf
Step 2: Choose Required Options (only one of the following from each list unless otherwise
Step 2: Choose Required Options (only one of the following from each list unless otherwiseStep 2: Choose Required Options (only one of the following from each list unless otherwise
Step 2: Choose Required Options (only one of the following from each list unless otherwise
noted)
noted)noted)
noted)
HP Processors
HP ProcessorsHP Processors
HP Processors Quad-Core Processor
Quad-Core ProcessorQuad-Core Processor
Quad-Core Processor
Intel® Xeon® processor X3370 (3.00GHz, 95W, 1333MHz FSB, 12MB), FIO 535026-L21
Intel® Xeon® processor X3360 (2.83GHz, 95W, 1333MHz FSB, 12MB), FIO 493261-L21
Intel® Xeon® processor X3330 (2.66 GHz, 95W, 1333 MHz FSB, 6MB), FIO 493259-L21
Intel® Xeon® Processor X3220 (2.40 GHz, 95W, 1066 MHz FSB, 8MB), FIO 455069-L21
Intel® Xeon® Processor X3210 (2.13 GHz, 95W, 1066 MHz FSB, 8MB), FIO 455068-L21
Dual-Core Processor
Dual-Core ProcessorDual-Core Processor
Dual-Core Processor
Intel® Xeon® processor E3120 (3.16 GHz, 65W, 1333 MHz FSB, 6MB), FIO 492973-L21
Intel® Xeon® processor E3110 (3.00 GHz, 65W, 1333 MHz FSB,6MB),FIO 464376-L21
Intel® Core™ 2® processor E7400 (2.80 GHz, 65W, 1066MHz FSB, 3MB), FIO 533838-L21
Intel® Pentium® processor E2160 (1.8GHz, 65W, 800 MHz FSB, 1MB), FIO 450359-L21
Single-Core Processor
Single-Core ProcessorSingle-Core Processor
Single-Core Processor
Intel® Celeron® processor 440 (2.0GHz, 35W, 800 MHz FSB, 512KB), FIO 455072-L21
HP Memory
HP MemoryHP Memory
HP Memory HP 2GB (1x2GB) Dual Rank PC2-6400 (DDR2-800) Unbuffered Memory Kit 450260-B21
HP 1GB (1x1GB) Dual Rank PC2-6400 (DDR2-800) Unbuffered Memory Kit 450259-B21
QuickSpecs
HP ProLiant ML110 Generation 5 (G5)
HP ProLiant ML110 Generation 5 (G5)HP ProLiant ML110 Generation 5 (G5)
HP ProLiant ML110 Generation 5 (G5)
Configuration Information-Factory Integrated Models
DA - 12867 Worldwide — Version 30 — June 21, 2010 Page 11
