HP R3000 User Manual

Spares 63
Spares
Ordering spares
To order a spare, visit the HP website (http://www.hp.com/buy/parts).
To replace parts under warranty, contact an HP authorized service representative.
UPS spare parts list
Item Description Spare part number
1 UPS unit NA/JPN 517699-001
* UPS unit HV NA/JPN 517700-001
* UPS unit INTL 517701-001
2 X-slot serial card 419180-001
3 Battery module 517703-001
* Mounting rails with screws 419181-001
* UPS/ERM mounting brackets 582931-001
* Cord retention clips 407409-001
* Serial download cable 397642-001
* not shown

HP R3000 Specifications

General

Model	R3000
Capacity	3000 VA / 2700 W
Rack Size	2U
Frequency	50/60 Hz
Output Voltage	230V
Input Voltage	230V
Battery Type	Sealed Lead Acid (SLA)
Interface	Serial, USB
Output Connections	IEC 320 C13, IEC 320 C19
Transfer Time	4 ms
Efficiency	95%
Operating Temperature	0°C to 40°C
Storage Temperature	-15°C to 45°C
Humidity	5% to 95% non-condensing
Dimensions	432 x 88 x 650 mm
