Domain join allowed
●
Operating system maximum number of users: 20 (see
Performance Considerations on page 8)
Description of Modes
Microsoft Windows MultiPoint Server 2011 can operate in two different modes described below:
●
Maintenance, see
Maintenance on page 2
●
Normal, see
Normal on page 2
Maintenance
Maintenance mode is the state of the MultiPoint Server 2011 system in which the administrative user
performs maintenance tasks. No stations switch to this mode—this mode ends all user sessions. All
software and driver installations are performed in Maintenance mode, including updating system
settings.
Maintenance Mode can be accessed by choosing "Switch to Maintenance Mode" from within the
MultiPoint Manager.
Normal
Normal mode is the default mode. Users normally log in and perform individual task on each station in
Normal mode. Each session runs a separate RDP session. Software updates and driver installations
should not be performed in Normal mode.
Remapping Stations
MultiSeat uses an auto-mapping function to associate each attached zero client. If the auto-mapping
function fails to work, then the user can manually associate their workstation with this function. Auto-
mapping does not apply to the host PC station. The remap function could be used to reconfigure the
host PC station’s association if the configuration has changed.
To perform this action, choose "Remap all stations" from the MultiPoint Manager.
Topology
●
Windows MultiPoint Server 2011
◦
Windows MultiPoint Server 2011 supports PS/2 keyboard/mouse on the host system.
◦
Windows MultiPoint Server 2011 supports audio and microphone on the host PC station.
NOTE: For this to function, the host stations must be configured using PS/2 keyboard and
mouse. It will not function with USB keyboard or mouse.
◦
Windows MultiPoint Server 2011 supports daisy-chaining of client devices connected by USB
cable. Daisy-chaining can simplify cabling and extend the distance between the host and a
station without additional USB hubs.
2 Chapter 1 Fundamentals

HP T200 Specifications

General

Motherboard chipset	-
Processor frequency	- GHz
Internal memory	- GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Display included	No
Audio system	Stereo audio
Microphone in	Yes
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	1
Power supply	3 W
Storage media	HDD
Storage drive interface	Serial ATA
Maximum resolution	2048 x 1152 pixels
Cabling technology	10/100/1000Base-T(X)
Operating system installed	Windows MultiPoint Server 2011
Product color	Black
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR
Country of origin	China

Weight and Dimensions

Depth	91 mm
Width	136 mm
Height	35 mm
Weight	343 g
