HP TOUCHSMART 9100 Quickspecs

System Unit Dimensions (HxWxD) 17.6 in x 22.8 in x 2.8 in
447 mm x 579 mm x 72 mm
Weight Approx. 25.4 lb (11.5 kg)
Stand-Alone Power
Requirements
Electrical Ratings 100–240 V, 50/60 Hz, 2.0 A
Average Operating Power 35 W Idle
Max Operating Power < 150 W
Temperature Operating 41° to 95° F (5° to 35° C)
Non-operating –22° to 149° F (-30° to 65° C)
Relative Humidity Operating 15% to 80% @ 26º C
Altitude
(unpressurized)
Operating 0 to 6,562 ft (0 to 2000 m)
Non-operating 0 to 15,000 ft (0 to 4,572 m)
Industry Standard
Certifications
UL Yes
CSA Yes
FCC Compliance Yes
ENERGY STAR
®
Yes
EPEAT Silver
For accessibility information on HP products, please visit: http://www.hp.com/accessibility .
Eco-Label Certifications This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:
US Energy Star
IT ECO declaration
EPEAT – Silver
System Configuration The configuration used for the Energy Consumption and Declared Noise Emissions data for this desktop
model is based on a typically configured product
Energy Consumption 115 VAC 230 VAC 100 VAC
Normal Operation 51.66 W 50.32 W 52.11 W
Sleep (Energy Star low
power mode)
3.392 W 3.456 W 3.37 W
Off 0.557 W 0.628 W 0.555 W
Heat Dissipation * 115 VAC 230 VAC 100 VAC
Normal Operation 177 BTU/hr 172 BTU/hr 178 BTU/hr
Sleep 12 BTU/hr 12 BTU/hr 12 BTU/hr
Off 2 BTU/hr 2 BTU/hr 2 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one
hour.
This product is in compliance with US executive order 13221, WOL (wake on LAN) disabled.
QuickSpecs
HP TouchSmart 9100 All-in-One PC
Technical Specifications
DA - 13434 North America — Version 8 — December 12, 2011 Page 11

HP TOUCHSMART 9100 Specifications

General

Processor cache	2 MB
Processor cores	2
Processor family	Intel® Core™2 Duo
Processor frequency	2.1 GHz
Processor cache type	L3
Processor manufacturer	Intel
Processor front side bus	800 MHz
Chassis type	All-in-One
Display included	Yes
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Graphics card family	NVIDIA
Floppy drive installed	No
Parallel ports quantity	0
Maximum graphics card memory	- MB
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Number of processors installed	1
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Discrete graphics card model	NVIDIA GeForce 200
Operating system installed	Windows 7 Professional
USB 2.0 ports quantity	5
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Product color	Black
Country of origin	China

Weight and Dimensions

Depth (with stand)	72 mm
Width (with stand)	579 mm
Height (with stand)	447 mm
Weight (with stand)	11500 g
