Setting Up the Monitor
User’s Guide 3–3
Preparing the monitor for wall-mounting
1. Disconnect the power cable and any other cables from the monitor.
2. Place the monitor face down on a flat, protected surface.
3. Remove the monitor base cover by inserting a screw driver into the slots and prying the cover off.
Inserting screwdriver into slots to remove monitor base cover
4. Lift the cover off the bottom of the monitor.
Removing the base cover away from the monitor
WARNING: To reduce the risk of personal injury or of damage to the equipment, check that the wall-mounting
fixture is adequately installed and secured before attaching the monitor. Refer to the instructions supplied with the
wall-mounting fixture and check that it is capable of supporting the monitor.
