HP ZBook 15 User Manual

6 Removal and replacement
procedures for Authorized Service
Provider parts
CAUTION: Components described in this chapter should only be accessed by an authorized service
provider. Accessing these parts can damage the computer or void the warranty.
Component replacement procedures
This chapter provides removal and replacement procedures for Authorized Service Provider only parts.
There are as many as 74 screws that must be removed, replaced, and/or loosened when servicing the
computer. Make special note of each screw size and location during removal and replacement.
RTC battery
Description Spare part number
RTC battery (includes cable and double-sided adhesive) 734300-001
Before removing the RTC battery, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 50).
5. Remove the service cover (see
Service cover on page 51).
Remove the RTC battery:
1. Disconnect the RTC battery cable (1) from the system board.
Component replacement procedures
69

HP ZBook 15 Specifications

General

Form factor	Clamshell
Product type	Mobile workstation
Product color	Black
Country of origin	China
Bus type	DMI2
Stepping	C0
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
Processor model	i7-4900MQ
System bus rate	- GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4900 Mobile Series
Processor socket	PGA946
Processor threads	8
Processor codename	Haswell
Processor frequency	2.8 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.8 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	47 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM87
Memory slots	4x SO-DIMM
Internal memory	16 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
Optical drive type	Blu-Ray DVD Combo
Card reader integrated	Yes
Total storage capacity	256 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	0x416
Discrete graphics card model	NVIDIA® Quadro® K1100M
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1300 MHz
Audio system	DTS Studio Sound HD
Number of built-in speakers	2
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Keyboard layout	-
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Processor code	SR15K
Processor ARK ID	75131
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 x 4.7 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Battery capacity	83 Wh
Battery life (max)	- h
AC adapter power	150 W
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	257 mm
Width	381.5 mm
Height	30.5 mm
Weight	2820 g
