Huawei E5730s-2 Product Description

HUAWEI E5730s-2 Mobile WiFi V200R001
Product Description
Issue 03 (2013-12-09)
Commercial in Confidence
Page 8 of 21
2 Features
2.1 Main Features
The E5730s-2 mainly supports the following features:

DC-HSPA+ (DL) data service of up to 43.2 Mbit/s

DC-HSPA+ (UL) data service of up to 5.76 Mbit/s

HSPA+ (DL) data service of up to 21.6 Mbit/s

HSPA+ (UL) data service of up to 5.76 Mbit/s

HSDPA (DL) data service of up to 14.4 Mbit/s

HSUPA (UL) data service of up to 5.76 Mbit/s

UMTS data service of up to 384 kbit/s

EDGE data service of up to 236.8 kbit/s

GPRS data service of up to 85.6 kbit/s

PS domain data service based on UMTS and GSM

SMS based on CS/PS domain of GSM and UMTS

Wi-Fi

Five-second fast boot

Support for HUAWEI Mobile WiFi App

Supplying power to devices

Plug and Play (PnP)

Built-in DHCP Server, DNS RELAY and NAT

Online software upgrade

Traffic statistic

Ethernet port

PPPoE dial up

MAC address cloning

Standard Micro USB interface

LED indicators

Built-in UMTS and WLAN high gain antenna

Windows XP SP3, Windows Vista SP1/SP2, Windows 7, Windows 8 (does not
support Windows RT), MAC OS X 10.6, 10.7 and 10.8 with latest upgrades

Huawei E5730s-2 Specifications

General

Brand	Huawei
Model	E5730s-2
Category	Wireless Router
Language	English
