Device parameters
The device parameters include the ONT's size, weight, operating environment, and power
parameters and equipment power consumption.
Table 1-11 HG8012H device parameters
Parameter Specifications
Dimensions (length x width x height) 135 mm x 115 mm x 30 mm
Weight About 500 g
Working environment Operating temperature: 0ºC to 40ºC
Environment humidity: 5% RH to 95% RH
(non-condensing)
Pressure environment: 86 kPa to 106 kPa
Altitude: 2000 m
Power specifications Power adapter input: 100 V AC to 240 V AC,
50 Hz to 60 Hz
System power supply: 11 V DC to 14 V DC,
1 A
Power consumption
l Static power consumption: 3 W
l Maximum power consumption: 6 W
1.4.3 HG8010H
Introduced the appearance, interfaces, LEDs and device parameters of the HG8010H.
EchoLife HG8040H/HG8012H/HG8010H GPON Terminal
Product Description 1 Introduction
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12
