EchoLife HG8245A/HG8245H/HG8240A/HG8045A
GPON Terminal
Product Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Appearance
Figure 1-17 Appearance of the HG8245A
Port/Button
Figure 1-18 and Figure 1-19 show the ports on the rear panel and side panel of the HG8245A
respectively.
Figure 1-18 Ports and buttons on the rear panel of the HG8245A
Table 1-19 Description of ports and buttons on the rear panel of the HG8245A
Indicates the power button. It is used to power on or power
off the device.
Indicates the power port, used to connect to the power
adapter or backup battery unit.
Indicates USB host port, used to connect to USB storage
devices.
Indicates VoIP telephone ports (RJ-11), used to connecting to
