Connecting Cables
5
Cable Connections Between the HG8240 and Other Devices
4
3
6
5
7
2
1
1
Optical port in the wall
2
PC
3
IP set-top box (STB)
4
TV set
5
Telephone set
6
Fax machine
7
Power adapter
8
Backup battery unit
BBU RESET
8
