7
Connecting Cables
This document uses the HG8247H as an example to describe the
connections. Ports on GPON terminals of other types may be different.
Therefore, connect cables based on the ports that are actually supported
by the device. If the external device is different from the device in the figure,
refer to the description for connections of the external device.
1
Power switch
2
Power port
3
USB port
4
POTS port
5
Ethernet port
6
Optical port
7
CATV port
8
Reset
9
WLAN switch
10
WPS switch
1
2
5
4
6
7
3
Fax machine
Phone
PC
TV set
IP STB
Optical port
Power socket
USB storage device
TV set
Wi-Fi terminal
8
9
10
