Huawei HG532e User Manual

19
6 Technical Specifications
6.1 Indicators
Indicator
Status
Description
Power On The HG532e is powered on.
Off The HG532e is powered off or faulty.
Internet Blinking
 The HG532e is working in routing mode, and it
is connected to the Wide Area Network (WAN).
 Data is being transmitted.
On
 The HG532e is working in routing mode, and it
is connected to the WAN.
 No data is being transmitted.
Off  The HG532e is working in bridge mode.
 The HG532e is working in routing mode, but it
is not set up the connection to the WAN.
ADSL Blinking The ADSL connection is being activated.
On The ADSL connection is set up and activated.
Off
No digital subscriber line (DSL) connection is set
up, or the DSL connection is faulty.

Huawei HG532e Specifications

General

Wireless Standard	802.11b/g/n
Frequency Band	2.4 GHz
Ethernet Ports	4 x 10/100 Mbps
ADSL Standard	ADSL2+
Wireless Speed	Up to 300 Mbps
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Power Supply	12V DC, 1A
Security	WEP, WPA, WPA2
Operating Humidity	5% to 95% (non-condensing)
Ports	1 x RJ11, 4 x RJ45
