According to Article 10 (10) of Directive 2014/53/EU, the
packaging shows that this radio equipment will be subject
to some restrictions when placed on the market in Belgium
(BE), Bulgaria (BG), the Czech Republic (CZ), Denmark
(DK), Germany (DE), Estonia (EE), Ireland (IE), Greece
(EL), Spain (ES), France (FR), Croatia (HR), Italy (IT),
Cyprus (CY), Latvia (LV), Lithuania (LT), Luxembourg (LU),
Hungary (HU), Malta (MT), Netherlands (NL), Austria (AT),
Poland (PL), Portugal (PT), Romania (RO), Slovenia (SI),
Slovakia (SK), Finland (FI), Sweden (SE), the United
Kingdom (UK), Turkey (TR), Norway (NO), Switzerland
(CH), Iceland (IS), and Liechtenstein (LI).
The WLAN function for this device is restricted to indoor
use only when operating in the 5150 to 5350 MHz
frequency range.
Frequency Bands and Power
(a) Frequency bands in which the radio equipment
operates: Some bands may not be available in all countries
or all areas. Please contact the local carrier for more
details.
(b) Maximum radio-frequency power transmitted in the
frequency bands in which the radio equipment operates:
The maximum power for all bands is less than the highest
limit value specified in the related Harmonized Standard.
The frequency bands and transmitting power (radiated
and/or conducted) nominal limits applicable to this radio
equipment are as follows:
POT-
LX1A
GSM900: 35dBm, GSM1800: 32dBm,
WCDMA900/2100: 25.7dBm, LTE Band
1/3/7/8/20: 25.7dBm, Wi-Fi 2.4G: 20dBm, Wi-
Fi 5G: 5150-5250MHz: 23dBm,
5250-5350MHz: 20dBm, 5470-5725MHz:
23dBm, 5725-5850MHz: 14dBm, Bluetooth:
20dBm, NFC: 42 dBuA/m at 10 m
POT-LX3 GSM900: 35dBm, GSM1800: 32dBm,
WCDMA900/2100:25.7dBm, LTE Band 7/28:
25.7dBm, Wi-Fi 2.4G: 20dBm, Bluetooth:
20dBm
Accessories and Software Information
Some accessories are optional in certain countries or
regions. Optional accessories can be purchased from a
licensed vendor as required. The following accessories are
recommended:
8
