52
Operating Features ...........................................
✔ Independently assign each station’s cycle lengths, number of
cycles per day, and days between watering.
✔ Cycle each station to water up to 28 times per day (14 times per
program).
✔ No fuse needed: electronic short circuit detection warns of a
short, then continues to next station.
✔ No battery needed: programs stored for up to 10 continuous
hours. With optional battery, programs saved for up to 7 months.
✔ Adjust delay time between watering cycles, from 30 min. to
12 hrs., in one-hour steps.
✔ With one touch, pause automatic watering, then restart.
✔ Press the Rain button to stop automatic watering indefinitely.
✔ Set days on which no watering will occur.
✔ Manually run an entire program or a single station at any time.
✔ At the touch of a button, make seasonal adjustments for wet or
dry spells.
✔ Set up two completely different programs, A and B, to meet
diverse watering needs (drip and spray, for example). It's like
having two controllers.
✔ Lock cover to resist tampering.
✔ Connect a rain sensor directly to the controller, or manually
override the sensor simply by pressing a button.
✔ Rely on proven superior surge protection.
✔ Connect to a 24V master valve or pump relay.
✔ Maximum run time: 3 hours, 59 minutes per station.
Specifications ....................................................
Primary input voltage: 220 V
Nominal, 50/60 Hz.
Station output voltage: 24 V ,
0.5A maximum.
Pump/master valve output
voltage: 24 V , 0.5A maximum.
Conduit size: Primary power
conduit size:
1
/
2
" (13 mm); field
wiring conduit size: 1" (25 mm)
to 1
1
/
2
" (38 mm).
Valves per station: Maximum 2
standard-draw solenoids or 6
Hunter low-current solenoids.
Optional battery: 9 volt
alkaline.
Field wiring size: 14 AWG
maximum.
Rain sensor: Interrupt type.
Surge protection: MOV type on
each station and primary power.
