Husqvarna 120iTK4-H User Manual

Contents
Introduction.....................................................................4
Safety..............................................................................5
Assembly...................................................................... 11
Operation......................................................................11
Maintenance................................................................. 13
Troubleshooting............................................................15
Transportation, storage and disposal........................... 16
Technical data.............................................................. 16
Declaration of Conformity............................................. 18
Introduction
Product description
Husqvarna 120iTK4-H is a battery telescopic pole hedge
trimmer.
Work is constantly in progress to increase your safety
and efficiency during operation. Speak to your servicing
dealer for more information.
Intended use
Use the product to cut branches and twigs. Do not use
the product for other tasks.
Product overview
(Fig. 1)
1. Blade
2. Transport guard
3. Housing
4. Position split handle
5. Telescopic function
6. Front handle
7. Shaft
8. Harness support hook
9. Keypad
10. Power trigger lockout
11. Power trigger
12. Rear handle
13. Battery charger QC80
14. Power Cord
15. Power on and warning indicator
16. Battery
17. Battery release buttons
18. Battery indicator button
19. Warning LED
20. Battery indicator LED
21. Start/Stop button
22. SavE button
23. Warning LED
24. Operator's manual
25. Harness
26. Connector
27. Battery charger 40-C80
Symbols on the product
(Fig. 2)
WARNING! This product is dangerous.
Injury or death can occur to the operator
or bystanders if the product is not
used carefully and correctly. To prevent
injury to the operator or bystanders,
read and obey all safety instructions in
the operator's manual. Please read the
operator's manual carefully and make
sure that you understand the instructions
before use.
(Fig. 3)
Use a protective helmet in locations where
objects can fall on you. Use approved
hearing protection. Use approved eye
protection.
(Fig. 4)
Use approved protective gloves.
(Fig. 5)
The product agrees with the applicable
EC directives.
(Fig. 6)
Rated voltage, V
(Fig. 7)
Direct current.
(Fig. 8)
Do not expose to rain.
(Fig. 9)
Keep hands away from blade.
(Fig. 10)
Telescopic function.
(Fig. 11)
Split function.
(Fig. 12)
Turn left to loose the knob, turn right to
tighten the knob.
(Fig. 13)
This product does not have insulation.
If the product touches or comes near
high-voltage power lines, it can cause
death or bad injury. The current can
4 1553 - 008 - 31.10.2022
