unit 130 (H13038HV) 135 Mark II
(H13038HV)
Sound power level, guaranteed (L
WA
)
3
dB(A) 116 116
Sound power level, measured
4
dB(A) 114 114
Sound pressure level at operator's ear
5
dB(A) 102 102
Product dimensions
Weight (excluding cutting equipment) kg 4.68 (10.3) 4.68 (10.3)
Oil tank volume cm
3
260 260
Fuel and lubrication system
Oil pump capacity at 9000 min
-1
ml/min 9 9
Type of oil pump — Automatic Automatic
Saw chain and guide bar
Standard guide bar length cm (in) 35-40 (14-16) 35-40 (14-16)
Recommended guide bar length cm (in) 35-40 (14-16) 35-40 (14-16)
Usable cutting length cm (in) 33-38 (13-15) 33-38 (13-15)
Maximum saw chain speed m/s 22.3 22.3
Saw chain pitch mm (in) 9.52 (3/8) 9.52 (3/8)
Thickness of drive links (gauge) mm (in) 1.3 (0.050) 1.3 (0.050)
Type of drive sprocket — Spur Spur
Number of drive sprocket teeth — 6 6
ACCESSORIES
Guide bar and saw chain combinations
Guide bar
Saw chain
Length Pitch Gauge Max. nose radi-
us
Type Drive link count
14 inch 3/8 inch 0.050 inch 7T Husqvarna H37
Husqvarna S93G
52
16 inch 56
3
Noise emissions in the environment measured as sound power (L
WA
).
4
Noise emissions in the environment measured as sound power (L
WA
).
5
Equivalent sound pressure level is calculated as the time-weighted energy total for different sound pressure
levels under various working conditions. Typical statistical dispersion for equivalent sound pressure level is a
standard deviation of 2.5 dB(A).
22 862 - 001 - 20.09.2018
