16 – English
USING THE BLOWER
WARNING!
When fitting the blower tube and
nozzle, the engine must be
switched off and the stop switch
must be in the stop position.
!
The blower tube and nozzle have a bayonet mount.
Fit them in the following manner:
1. Press the blower tube (15) against the blower air
outlet and turn it 90 degrees until a snap is
heard.
2. Fit the nozzle (14) onto the tube (15), and turn it
90 degrees until a snap is heard.
To blow away debris on the
ground
Fitting the blower tube and nozzle
on the blower
Blowing
Before you begin blowing, put on the required safety
equipment.
WARNING!
When working with the blower,
wear the required protecting
equipment:
1. Hearing protection.
2. Eye protection.
3. Face mask in dusty environ-
ments.
!
When operating the blower, the blower must be
secured to the shoulder strap. The strap should be
worn over the shoulder as shown in the adjacent
figure.
15
14
