Husqvarna 225L User Manual

English – 11
26
25
¥
¢
27
=
WHAT IS WHAT?
What is what on the trimmer?
1. Trimmer head
2. Grease filler cap
3. Angle gear
4. Spray guard
5. Shaft
6. Loop handlebar
7. Throttle
8. Stop switch
9. Throttle trigger lock
10. Suspension for harness (not on 225L Lite)
11. Cylinder cover
12. Starter handle
13. Fuel tank
14. Choke
15. Air filter cover
16. Clutch cover
17. Handlebar adjustment
18. Locking nut
19. Support flange
20. Drive disc
21. Shaft coupling (225LD)
22. Socket spanner
23. Operator‘s Manual
24. Harness
25. Allen key
26. Carburettor screwdriver
27. Locking pin

Husqvarna 225L Specifications

General

Brand	Husqvarna
Model	225L
Category	Lawn and Garden Equipment
Language	English
