Husqvarna 359 User Manual

English – 39
TECHNICAL DATA
Note: For the saw chains above (if available) you are free to choose between 0,050" or 0,058" gauge drive links for the
corresponding bar, see the table below.
Saw chain filing and file gauges
Bar Chain
Length, inch Pitch, inch Gauge, inch Max. nose radius Type Drive link count
13 0,325 1,5 10T
Husqvarna H25
56
15 0,325 1,5 10T 64
16 0,325 1,5 10T 66
18 0,325 1,5 10T 72
20 0,325 1,5 12T 78
13 0,325 1,5 10T
Husqvarna H30
56
15 0,325 1,5 10T 64
16 0,325 1,5 10T 66
18 0,325 1,5 10T 72
20 0,325 1,5 10T 78
15 3/8" 1,5 11T
Husqvarna H42
56
16 3/8" 1,5 11T 60
18 3/8" 1,5 11T 68
20 3/8" 1,5 11T 72
24 3/8" 1,5 11T 84
0,050” H30 H22
0,058” - H25

Husqvarna 359 Specifications

General

Engine displacement	59.2 cm³
Power output	3.5 kW / 4.7 hp
Weight	5.5 kg
Fuel tank volume	0.5 L (16.9 fl oz)
Oil tank volume	0.26 L (8.8 fl oz)
Weight (excl. cutting equipment)	5.5 kg
Chain pitch	3/8"
Weight (without cutting equipment)	5.5 kg
Chain gauge	0.058 "
