ASSEMBLY
English – 17
6 The elastic strap (B) can be tightened to transfer more
load from the shoulder straps to the hip strap.
Balance XT
(545FX, 545FXT, 545RXT)
Safety release
Push down the red release lever to release the machine
from the harness.
Adjusting the harness
1 Adjust the harness to suit the person's height. Move
the shoulder strap attachment to a suitable hole in the
back plate by pressing in the spring-loaded lock and
twisting the shoulder strap attachment.
2 Tighten the hip strap so that it sits securely.
3 The hip belt should hang roughly in line with the hip
bone.
4 Press the breast plate together.
5 Attach the side belt to the breast plate.
6 To relieve pressure on the rib cage, it is possible to
connect the side belt with a belt to the hip pad.
(Suitable for females).
A
B

Husqvarna 545FX Specifications

General

Cylinder Displacement	45.7 cm³
Vibration Level Front Handle	3.2 m/s²
Power Output	2.1 kW
Engine Type	2-stroke
Fuel Tank Volume	0.9 l
