6 – English
2.3 To disassemble/assemble the
front cabinet and accessory storage
1. Tools: Torx 20 screwdriver and at screwdriver.
2. Remove the handle by pressing the 2 * 2 snap locks.
Loosen one side rst and then the other side.
3. Remove the 2 torx TX20 screws (A) from the rear side.
A
A
4. Loosen the front cabinet from the accessories
storage. Use a screwdriver on both sides, see gure
below. Remove the accessories storage.
5. Lift up the front cabinet to remove it.
Assembly: Place the accessories storage on the front
cabinet and push it in place until you hear a “click”. Install
the 2 screws.
