This operator manual describes the Husqvarna Zero Turn
Rider. The rider is fitted with a Briggs & Stratton four-stroke
overhead valve engine.
Transmission from the engine is made via a belt-driven
hydraulic pumps. Using the left and right steering controls, the
flow is regulates the direction and speed.
Control Locations
1
2
6
10
9
4
5
12
7
3
11
8
5
1. Steering/Brake levers 7. Fuel tank
2. Tracking adjustment, left side 8. Throttle control
3. Deck lift 9. Service meter
4. Fuses 10. Ignition switch
5. Bypass linkages 11. Blade switch
6. Fuel shut off valve 12. Seat adjustment lever
