Husqvarna Z 554 Series User Manual

2
3
4
5
12
11
10
9
8
7
1
6
13
14
15
2
5
3
This operator manual describes the Husqvarna
Zero Turn Rider. The rider is tted with a four-
stroke overhead valve engine.
Transmission from the engine is made via
belt-driven hydraulic pumps. Using the left and
right steering controls, the ow is regulated and
thereby the direction and speed.
1. Steering / park brake controls
2. Tracking controls
3. Fuel gauges
4. Service meter
5. Fuel tank caps
6. Fuses
7. Fuel tank selector
8. Choke control
9. Ignition switch
10. Throttle control
11. Blade switch
12. Seat adjustment lever
13. Deck height pin
14. Deck lift pedal
15. Deck release pedal
12
CONTROLS

Husqvarna Z 554 Series Specifications

General

Brand	Husqvarna
Model	Z 554 Series
Category	Lawn Mower
Language	English
