HUSTLER 50 - Maintenance Locator Chart

111132_0409 4-9
9
1. Engine oil fill & dipstick
2. Fuel filter
3. Engine air cleaner
4. Engine oil drain plug
5. Fuel tank
6. Traction drive belt (2)
7. Grease zerk (6 places)
8. Front roller mount bracket
9. Cutting reel drive belt
10. Main drive belts (2)
1
2
3
4
5
8
8
Maintenance Locator Chart
7
10
7
7
6
6
