DO-IT-YOURSELF MAINTENANCE
6-2
G010B01O-AAT
ENGINE COMPARTMENT (2.7 V6)ENGINE COMPARTMENT (2.7 V6)
ENGINE COMPARTMENT (2.7 V6)ENGINE COMPARTMENT (2.7 V6)
ENGINE COMPARTMENT (2.7 V6)
1. Coolant reservoir cap
2. Brake fluid reservoir
3. Air cleaner
4. Fuse and Relay box
5. Windshield washer fluid reservoir
6. Power steering fluid reservoir
7. Engine oil level dipstick
8. Radiator cap
9. Engine oil filler cap
10. Auto transaxle fluid level dipstick (Vehicle
with Auto T/A)
11. Battery
G010B01O
1
2
34
56 7 8 9 10 11
